MITSUBISHI D65UB004431 HR371-Y输入/输出接口板 PDF资料
MITSUBISHI D65UB004431 是三菱或马扎克机床用的输入输出接口板，上面带 HR371-Y 这块卡式 I/O 模块。它装在电控柜里，负责机器信号的输入输出。
产品特点
卡式 I/O 设计，HR371 插在控制 PCB 上，拆装方便。
源型输出，和 HR361 的漏型不一样，接线时要注意区分。
通道号可设，最多能连 8 块远程卡。
带状态指示灯，5V 通电亮绿灯，远程通讯报警亮红灯，排查问题直观。
每块卡 16 点输入、16 点输出，能覆盖不少信号点。
产品参数
输入输出点数：每卡 16 点输入、16 点输出。
供电：外部 24V 直流加减 5%，内部 5V 直流加减 5%。
输出类型：源型。
尺寸：55 毫米乘 93 毫米，小卡尺寸。
连接器：CF30，50 针。
应用领域
三菱 MELDAS M600 系列数控系统，作为卡式 I/O 扩展用。
马扎克机床，D65UB004431 这个板号就是马扎克 Fusion 640 控制系统的 I/O 板。
机床电控柜信号接口，连接继电器板等，做机器侧的输入输出。
数控机床维修备件，老设备维护时替换用。
远程 I/O 站点，通过远程 I/O 控制器连到 NC 系统。
总的来说，这块板子就是三菱 M600 系统或马扎克机床里管输入输出的卡，HR371-Y 是上面的核心模块。换的时候记得断电操作，别带电插拔。
MITSUBISHI D65UB004431 HR371-Y输入/输出接口板 英文介绍
MITSUBISHI D65UB004431 is an input/output interface board used by Mitsubishi or Mazak machine tools, which is equipped with the HR371-Y card type I/O module. It is installed in the electrical control cabinet and is responsible for the input and output of machine signals.
Product Features
Card type I/O design, HR371 can be plugged into the control PCB for easy disassembly and assembly.
The source output is different from the drain type of HR361, so it is important to distinguish between them when wiring.
The channel number can be set, and up to 8 remote cards can be connected.
Equipped with a status indicator light, the 5V power on lights up green, and the remote communication alarm lights up red, making troubleshooting intuitive.
Each card has 16 input points and 16 output points, which can cover many signal points.
Product Specifications
Input/output points: 16 input points and 16 output points per card.
Power supply: External 24V DC plus or minus 5%, internal 5V DC plus or minus 5%.
Output type: Source type.
Size: 55mm by 93mm, small card size.
Connector: CF30, 50 pin.
Application Areas
Mitsubishi MELDAS M600 series CNC system, used as a card type I/O expansion.
The board number D65UB004431 of Mazak machine tool is the I/O board of Mazak Fusion 640 control system.
Machine tool electrical control cabinet signal interface, connecting relay boards, etc., for machine side input and output.
Spare parts for CNC machine tool maintenance, used for replacing old equipment during maintenance.
Remote I/O site, connected to the NC system through a remote I/O controller.
In general, this board is the input/output card for Mitsubishi M600 system or Mazak machine tool, and HR371-Y is the core module on top. Remember to turn off the power when changing, and do not plug or unplug while the power is on.
MITSUBISHI D65UB004431 HR371-Y输入/输出接口板 产品图片
