TDI XBL-100-600-6000-AIR空气电子负载模块 PDF资料
这个 TDI XBL-100-600-6000-AIR 是 TDI Power（现在归 Astrodyne TDI 旗下）的 Dynaload XBL 系列风冷直流电子负载。下面简单说说。
产品特点
TDI Power 原厂出品，属于 Dynaload XBL 系列，风冷散热设计。
6000W 功率等级，最高 100V 电压、600A 电流，适合大电流测试场景。
支持恒流、恒压、恒功率、恒阻和脉冲负载多种工作模式，波形灵活可调。
带可编程斜率控制，响应快，精度高，适合动态负载测试。
支持 GPIB、以太网和 RS232 接口，还能通过内置网页做本地控制和监控。
产品参数
品牌：TDI Power / Astrodyne TDI。
型号：XBL-100-600-6000-AIR。
功率：6000W。
电压范围：0 到 100V。
电流范围：0 到 600A。
冷却方式：风冷。
产品应用领域
燃料电池测试，模拟不同负载条件做性能评估。
电源测试，给直流电源做负载老化或动态响应测试。
电池测试，评估电池在不同放电电流下的表现。
军工和航空电子设备测试，验证直流供电系统的稳定性。
科研和产线自动化测试，配合 LabVIEW 做定制化负载模拟。
总的来说，TDI XBL-100-600-6000-AIR 就是 Dynaload XBL 系列的风冷直流电子负载，6000W、100V、600A，燃料电池、电源和电池测试里做大电流动态负载模拟用的。
TDI XBL-100-600-6000-AIR空气电子负载模块 英文介绍
This TDI XBL-100-600-6000-AIR is a Dynaload XBL series air-cooled DC electronic load from TDI Power (now under Astrodyne TDI). Below is a brief explanation.
Product Features
Produced by TDI Power, belonging to the Dynaload XBL series, with air-cooled cooling design.
6000W power level, maximum 100V voltage, 600A current, suitable for high current testing scenarios.
Supports multiple working modes including constant current, constant voltage, constant power, constant resistance, and pulse load, with flexible and adjustable waveforms.
Equipped with programmable slope control, fast response, high accuracy, suitable for dynamic load testing.
Supports GPIB, Ethernet, and RS232 interfaces, and can also perform local control and monitoring through built-in web pages.
Product Specifications
Brand: TDI Power/Astrodyne TDI.
Model: XBL-100-600-6000-AIR.
Power: 6000W.
Voltage range: 0 to 100V.
Current range: 0 to 600A.
Cooling method: air cooling.
Product application areas
Fuel cell testing, simulating different load conditions for performance evaluation.
Power testing, conducting load aging or dynamic response testing on DC power supplies.
Battery testing to evaluate the performance of batteries under different discharge currents.
Testing of military and aviation electronic equipment to verify the stability of DC power supply systems.
Research and production line automation testing, combined with LabVIEW for customized load simulation.
Overall, TDI XBL-100-600-6000-AIR is the Dynaload XBL series air-cooled DC electronic load, 6000W, 100V, 600A, used for simulating high current dynamic loads in fuel cell, power supply, and battery testing.
TDI XBL-100-600-6000-AIR空气电子负载模块 产品图片
