TEL MPC-T0070A-14 输入 / 输出模块 PDF资料
1.产 品 资 料 介 绍：
开头
TEL MPC-T0070A-14 是东京电子半导体设备中使用的数字量输入模块，用于采集现场设备的开关信号。
产品特点
制造商为东京电子，属于工业控制I/O接口板，输入专用。
-14代表第14个硬件修订版本，适配特定设备或系统平台。
用于采集设备中按钮、限位开关、接近传感器等开关量信号。
实时监测门状态、安全锁、机械位置等二进制状态信息。
自带光耦或电子隔离设计，防止外部干扰传入主控系统。
具备输入滤波功能，滤除机械抖动和瞬态干扰。
将输入信号编码后通过总线协议发送至上位控制系统。
安装在设备背板或控制机架中，作为信号转换和数据采集的桥梁。
工业级设计，适应半导体制造设备的连续运行环境。
与TEL设备控制系统深度集成，支持专用通信协议。
应用领域
ACT系列光刻前处理设备，检测载片台状态、气动门开关、晶圆在位信号。
Tactras系列蚀刻系统，采集腔体门锁开闭、真空状态检测开关、故障信号反馈。
Trias系列沉积系统，检测炉体机械运动状态、气体通断反馈、冷却通道反馈信号。
刻蚀机、沉积设备（CVD/PVD）、扩散炉、清洗设备等TEL半导体设备中的状态检测。
晶圆搬运与定位系统中的位置反馈和动作确认。
半导体生产线中各类安全联锁信号的采集。
设备维护和故障诊断中的状态监测。
需要高可靠性开关量信号采集的半导体制造场景。
结尾
总之，TEL MPC-T0070A-14 是东京电子半导体设备中专用的数字输入模块，用于采集各类开关量状态信号
TEL MPC-T0070A-14 输入 / 输出模块 英文介绍
beginning
TEL MPC-T0070A-14 is a digital input module used in Tokyo Electronic Semiconductor Equipment to collect switch signals from field devices.
Product Features
The manufacturer is Tokyo Electronics, which belongs to the industrial control I/O interface board and is dedicated to input.
-14 represents the 14th hardware revision version, adapted to specific devices or system platforms.
Used to collect switch signals such as buttons, limit switches, and proximity sensors in devices.
Real time monitoring of binary status information such as door status, safety lock, mechanical position, etc.
Equipped with optocoupler or electronic isolation design to prevent external interference from entering the main control system.
Equipped with input filtering function to filter out mechanical jitter and transient interference.
Encode the input signal and send it to the upper control system through the bus protocol.
Installed in the equipment backplane or control rack as a bridge for signal conversion and data acquisition.
Industrial grade design, suitable for continuous operation environment of semiconductor manufacturing equipment.
Deeply integrated with TEL device control system, supporting dedicated communication protocols.
Application Domain
ACT series lithography pre-processing equipment is used to detect the status of the wafer stage, pneumatic door switches, and wafer in-situ signals.
Tactras series etching system collects chamber door lock opening and closing, vacuum status detection switch, and fault signal feedback.
The Trias series sedimentation system detects the mechanical motion status of the furnace body, gas on/off feedback, and cooling channel feedback signals.
State detection in TEL semiconductor equipment such as etching machines, deposition equipment (CVD/PVD), diffusion furnaces, cleaning equipment, etc.
Position feedback and action confirmation in wafer handling and positioning system.
Collection of various safety interlock signals in semiconductor production lines.
Status monitoring in equipment maintenance and fault diagnosis.
Semiconductor manufacturing scenarios that require high reliability switch signal acquisition.
ending
In summary, TEL MPC-T0070A-14 is a digital input module specifically designed for Tokyo Electronic Semiconductor Equipment, used to collect various switch status signals
TEL MPC-T0070A-14 输入 / 输出模块 产品图片
