TDK-Lambda GENH750W 电源模块 PDF资料
1.产 品 资 料 介 绍：
TDK-Lambda GENH750W 是Genesys系列的一款可编程直流电源模块，额定输出功率750W，采用1U高度紧凑设计。
产品特点
属于TDK-Lambda Genesys系列，半机架尺寸设计。
支持单相交流输入，电压范围85至265Vac，频率47至63Hz。
额定输出功率750W，输出电压和电流可编程调节。
典型效率可达87%，电压纹波低至0.008Vrms。
外形尺寸为宽214mm、高43.6mm、深437.5mm，重量约4.5kg。
标配RS-232和RS-485通信接口，可选配LAN、USB、GPIB及隔离模拟控制接口。
工作温度范围0至50°C，符合多项国际安全标准。
支持远程电压检测功能，补偿负载线缆压降。
前面板采用编码器旋钮调节电压和电流，支持前面板锁定功能。
具备主动式功率因数校正，提高电能利用率。
应用领域
实验室和研发机构的电子设备测试。
工业自动化系统中的精密供电。
通信设备中网络组件的供电。
医疗设备研发和生产中的可编程电源。
半导体制造和测试设备的精密供电。
航空航天和国防领域电子系统的地面测试。
汽车电子零部件的性能测试和老化试验。
科研院校的教学实验和课题研究。
电池充电和模拟测试。
传感器和仪表的校准测试。
结尾
总之，TDK-Lambda GENH750W 是一款高功率密度、可编程的直流电源模块，适用于实验室测试、工业自动化和设备研发等场景。
TDK Lambda GENH750W is a programmable DC power module from Genesys series, with a rated output power of 750W and a 1U highly compact design.
Product Features
Belonging to the TDK Lambda Genesys series, with a half rack size design.
Supports single-phase AC input, voltage range 85 to 265Vac, frequency 47 to 63Hz.
The rated output power is 750W, and the output voltage and current are programmable and adjustable.
The typical efficiency can reach 87%, and the voltage ripple is as low as 0.008Vrms.
The external dimensions are 214mm wide, 43.6mm high, 437.5mm deep, and weigh approximately 4.5kg.
Standard RS-232 and RS-485 communication interfaces, optional LAN, USB, GPIB, and isolated analog control interfaces.
The working temperature range is 0 to 50 ° C, which complies with multiple international safety standards.
Support remote voltage detection function to compensate for load cable voltage drop.
The front panel adopts an encoder knob to adjust voltage and current, and supports front panel locking function.
Equipped with active power factor correction to improve energy utilization efficiency.
Application Domain
Electronic equipment testing in laboratories and research and development institutions.
Precision power supply in industrial automation systems.
Power supply for network components in communication equipment.
Programmable power supplies in the research and production of medical equipment.
Precision power supply for semiconductor manufacturing and testing equipment.
Ground testing of electronic systems in the aerospace and defense fields.
Performance testing and aging testing of automotive electronic components.
Teaching experiments and research projects in research institutions.
Battery charging and simulation testing.
Calibration testing of sensors and instruments.
ending
In summary, TDK Lambda GENH750W is a high power density, programmable DC power module suitable for laboratory testing, industrial automation, and equipment development scenarios.
