IC693PWR330 电源模块 PDF资料
1.产 品 资 料 介 绍：
电气规格
- 输入规格：宽压 AC 85~264V（标称 120/240VAC）；兼容 DC 100~300V 直流输入
- 整机总额定输出功率：30W（三路输出合计上限不可超标）
- 输出 1：+5VDC 逻辑供电，最高 30W，供给 CPU、背板总线、通讯模块核心芯片
- 输出 2：隔离型 24VDC，最大 20W，供给模拟量 AI/AO、数字输入模块现场馈电
- 输出 3：非隔离 24VDC 继电器电源，最大 15W，适配继电器型 DO 模块线圈供电
- 输入输出绝缘耐压：1500VAC 电气隔离
- 待机功耗：AC 输入满载约 90VA，DC 输入满载 50W
- 上电冲击电流内置软启动抑制
- 面板指示灯：POWER 运行绿灯、FAULT 故障告警红灯
- 安装形式：机架左侧插槽固定式安装，DIN 导轨配套整机机架固定
15 条核心特点
- IC693PWR330G 主打 5V 大功率输出，相比 PWR321（15W）可承载更多 CPU、以太网、Profibus 通讯卡与高密度 I/O 负载
- 宽幅电网适配，应对厂区电压骤升骤降、变频设备造成的电网畸变
- 三路独立供电分区，逻辑电源、隔离仪表电源、继电器负载电源互不干扰，避免感性负载反向电动势冲击 CPU 核心
- 内置过压、欠压、过载、短路四重硬件自锁保护，故障切断输出，断电重启复位
- 输入与输出高压隔离，阻断现场地环路干扰，保护主控背板芯片不被浪涌击穿
- 标准 90-30 机架即插即用，无需额外接线改造，替换旧电源直接上机识别
- 适配以太网 NIU、各类高级通讯模块，这类模块对 5V 供电功率要求较高，小功率电源易带载不稳
- 金属加固壳体，PCB 三防工艺，耐受造纸车间粉尘、潮湿、柜体震动工况
- 上电自带自检流程，自动检测各路输出电压，异常直接点亮 FAULT 告警灯锁定输出
- 不支持整机热插拔，更换前务必切断机架总输入电源，防止背板打火损坏触点
- 内部集成 EMI 滤波电路，削弱变频器、大功率电机带来的高频电磁干扰
- 同机架支持双电源冗余配置（配套冗余背板），关键工艺不间断供电
- 可搭配 CPU 后备电池，断电瞬间短暂稳压保障程序数据安全保存
- 区分同型号 IC693PWR331（24VDC 直流输入版），二者输入回路硬件不同不能互换
- CE、UL 工业安全认证，满足 7×24 小时连续不间断运行工况
环境参数
- 工作温度：0℃～+60℃
- 储存温度：-40℃～+85℃
- 相对湿度：5%～95% RH，无凝露
- 防护等级：IP20（控制柜内部使用）
- 整机重量：约 0.42kg
IC693PWR330G 电源模块 英文介绍
Electrical specifications
Input specifications: Wide voltage AC 85~264V (nominal 120/240VAC); Compatible with DC 100~300V DC input
Total rated output power of the whole machine: 30W (the total upper limit of the three outputs cannot exceed the standard)
Output 1:+5VDC logic power supply, up to 30W, supplied to CPU, backplane bus, communication module core chip
Output 2: Isolation type 24VDC, maximum 20W, providing on-site power supply for analog AI/AO and digital input modules
Output 3: Non isolated 24VDC relay power supply, maximum 15W, compatible with relay type DO module coil power supply
Input/output insulation withstand voltage: 1500VAC electrical isolation
Standby power consumption: AC input full load about 90VA, DC input full load 50W
Built in soft start suppression for power on surge current
Panel indicator lights: POWER running green light, FAULT fault alarm red light
Installation form: Fixed installation with slot on the left side of the rack, DIN rail matched with the whole machine rack for fixation
15 core characteristics
IC693PWR330G features a 5V high-power output, which can support more CPUs, Ethernet, Profibus communication cards, and high-density I/O loads compared to PWR321 (15W)
Wide range power grid adaptation to cope with voltage surges and drops in the factory area, as well as power grid distortions caused by frequency conversion equipment
Three independent power supply zones, logic power supply, isolation instrument power supply, and relay load power supply do not interfere with each other, avoiding the reverse electromotive force of inductive loads from impacting the CPU core
Built in hardware self-locking protection for overvoltage, undervoltage, overload, and short circuit, cutting off output in case of faults, restarting and resetting after power failure
Input and output high voltage isolation, blocking on-site ground loop interference, protecting the main control backplane chip from surge breakdown
Standard 90-30 rack plug and play, no need for additional wiring modifications, replace old power supply and directly recognize on the machine
Compatible with Ethernet NIU and various advanced communication modules, which require high 5V power supply and are prone to unstable load on low-power power supplies
Metal reinforced shell, PCB three proof process, resistant to dust, moisture, and cabinet vibration in the paper workshop
Equipped with a self check process upon power on, it automatically detects the output voltage of each channel. If there are any abnormalities, it will directly light up the FAULT alarm light and lock the output
The whole machine does not support hot swapping. Before replacement, be sure to cut off the main input power of the rack to prevent the backplane from igniting and damaging the contacts
Internally integrated EMI filtering circuit to reduce high-frequency electromagnetic interference caused by frequency converters and high-power motors
Same rack supports dual power redundancy configuration (with redundant backplane), ensuring uninterrupted power supply for critical processes
Can be paired with a CPU backup battery, providing brief voltage stabilization during power outages to ensure secure storage of program data
Distinguish between IC693PWR331 (24VDC DC input version) of the same model, as their input circuit hardware is different and cannot be interchanged
CE and UL industrial safety certification, meeting the continuous and uninterrupted operation conditions of 7 × 24 hours
