6SL3225-0BE25-5AA1 驱动功率模块 PDF资料
1.产 品 资 料 介 绍：
6SL3225-0BE25-5AA1 控制系统组件，核心特点如下（共15条）：
中间（15条）
西门子SINAMICS G120系列功率模块PM 250。
作为G120变频器的功率单元，需搭配控制单元使用。
输入电压为三相380-480V AC。
轻过载模式下功率为7.5kW。
重过载模式下功率为5.5kW。
内置集成A类进线滤波器，抑制电磁干扰。
具备能量回馈功能，将制动能量反馈回电网。
支持短时过载能力。
外形尺寸适合机柜安装。
防护等级IP20，适合控制柜内安装。
可与多种控制单元组合使用。
结合安全型控制单元可实现安全功能。
采用高效的IGBT技术。
具备完善的过载、短路保护功能。
符合RoHS环保标准。
结尾
总之，型号 6SL3225-0BE25-5AA1 具备能量回馈、过载能力强、设计紧凑等优势，是G120变频器系统的理想功率组件。
6SL3225-0BE25-5AA1 驱动功率模块 英文介绍
The core features of the 6SL3225-0BE25-5AA1 control system components are as follows (15 in total):
Middle (15 items)
Siemens SINAMICS G120 series power module PM 250.
As the power unit of G120 frequency converter, it needs to be used in conjunction with a control unit.
The input voltage is three-phase 380-480V AC.
The power in light overload mode is 7.5kW.
The power in heavy overload mode is 5.5kW.
Built in integrated A-class input filter to suppress electromagnetic interference.
Equipped with energy feedback function, the braking energy is fed back to the power grid.
Support short-term overload capability.
The external dimensions are suitable for cabinet installation.
Protection level IP20, suitable for installation inside control cabinets.
Can be used in combination with multiple control units.
Combined with a safety control unit, safety functions can be achieved.
Adopting efficient IGBT technology.
Equipped with comprehensive overload and short circuit protection functions.
Compliant with RoHS environmental standards.
ending
In summary, the model 6SL3225-0BE25-5AA1 has advantages such as energy feedback, strong overload capacity, and compact design, making it an ideal power component for the G120 inverter system.
6SL3225-0BE25-5AA1 驱动功率模块 产品图片
