MATROX 63039620987 图像采集卡 PDF资料
1.产 品 资 料 介 绍：
MATROX 63039620987 图像采集卡是Matrox公司生产的高性能图像采集与处理板卡，主要面向工业机器视觉和自动化检测应用，承担从相机采集图像信号并传输至主机的功能。
中间（15条特点）
制造商为Matrox，在机器视觉领域知名度较高。
属于Matrox工业级图像采集卡产品线。
采用PCIe总线接口，适配主流工控机平台。
板载帧存用于缓存高帧率图像，防止数据丢失。
支持Camera Link接口标准，可连接工业相机。
部分系列支持CoaXPress接口，传输速率高。
支持同时连接多台相机进行并行采集。
支持硬件级触发与I/O控制，实现多设备同步。
支持面阵相机和线阵相机两种类型。
支持8-48 bit图像位深，涵盖灰度与彩色模式。
部分型号支持FPGA预处理，减轻CPU负担。
提供MIL软件开发包及API接口。
支持Windows及Linux操作系统。
结构紧凑，适配工控机内部空间。
符合工业环境对可靠性和稳定性的要求。
结尾
总体而言，MATROX 63039620987 是一款性能可靠的工业级图像采集卡，能够满足机器视觉系统对图像采集与传输的常规需求。
The MATROX 63039620987 image acquisition card is a high-performance image acquisition and processing board produced by Matrox, mainly aimed at industrial machine vision and automation detection applications, responsible for capturing image signals from cameras and transmitting them to the host.
Middle (15 characteristics)
The manufacturer is Matrox, which is well-known in the field of machine vision.
Belonging to the Matrox industrial grade image acquisition card product line.
Adopting PCIe bus interface, compatible with mainstream industrial computer platforms.
Onboard frame memory is used to cache high frame rate images to prevent data loss.
Supports Camera Link interface standard and can connect industrial cameras.
Some series support CoaXpress interface with high transmission speed.
Support simultaneous connection of multiple cameras for parallel acquisition.
Support hardware level triggering and I/O control to achieve multi device synchronization.
Supports two types of cameras: area array cameras and line array cameras.
Supports 8-48 bit image depth, covering both grayscale and color modes.
Some models support FPGA preprocessing to reduce CPU burden.
Provide MIL software development kit and API interface.
Supports Windows and Linux operating systems.
Compact structure, suitable for the internal space of industrial control computers.
Meets the reliability and stability requirements of industrial environments.
ending
Overall, MATROX 63039620987 is a reliable industrial grade image acquisition card that can meet the conventional requirements of machine vision systems for image acquisition and transmission.
