B&R 5PC600.X945-00 工业计算机主板 PDF资料
1.产 品 资 料 介 绍：
B&R 5PC600.X945-00 是贝加莱工业自动化推出的一款CPU主板，主要用于APC620工业PC或PPC700面板PC，承担系统核心运算与数据处理功能。
中间（15条特点）
搭载Intel Atom N270处理器，主频1.6 GHz。
采用45 nm制造工艺，功耗较低。
配备Intel 945GME芯片组与ICH7-M南桥。
前端总线频率为533 MHz。
L2缓存容量为512 kB。
支持超线程技术与节能技术。
提供2个DDR2 SO-DIMM内存插槽，最大支持2 GB。
集成Intel GMA 950图形控制器。
支持RGB输出，分辨率可达2048×1536。
支持LVDS接口，分辨率最高1920×1200。
板载AMI BIOS引导程序。
配备电池供电的实时时钟。
支持1个EIDE接口，用于连接存储设备。
适用于APC620系统单元及PPC700面板PC。
符合CE和UKCA认证标准。
结尾
总体而言，B&R 5PC600.X945-00 是一款面向工业嵌入式应用的标准CPU主板，性能可靠、规格明确，能够满足自动化控制系统对基础运算与显示输出的需求。
B&R 5PC600.X945-00 工业计算机主板 英文介绍
B&R 5PC600.X945-00 is a CPU motherboard launched by B&R Industrial Automation, mainly used for APC620 industrial PCs or PPC700 panel PCs, responsible for system core computing and data processing functions.
Middle (15 characteristics)
Equipped with Intel Atom N270 processor, with a clock speed of 1.6 GHz.
Using a 45 nm manufacturing process, the power consumption is relatively low.
Equipped with Intel 945GME chipset and ICH7-M southbridge.
The front-end bus frequency is 533 MHz.
The L2 cache capacity is 512 kB.
Support hyper threading technology and energy-saving technology.
Provide 2 DDR2 SO-DIMM memory slots, supporting a maximum of 2 GB.
Integrated Intel GMA 950 graphics controller.
Supports RGB output, with a resolution of up to 2048 × 1536.
Supports LVDS interface, with a maximum resolution of 1920 × 1200.
Onboard AMI BIOS bootloader.
Equipped with a battery powered real-time clock.
Supports one EIDE interface for connecting storage devices.
Suitable for APC620 system units and PPC700 panel PCs.
Compliant with CE and UKCA certification standards.
ending
Overall, B&R 5PC600.X945-00 is a standard CPU motherboard designed for industrial embedded applications, with reliable performance and clear specifications, capable of meeting the basic computing and display output requirements of automation control systems.
B&R 5PC600.X945-00 工业计算机主板 产品图片
