AMAT 0190-03672 可控硅功率控制器 PDF资料
1.产 品 资 料 介 绍：
AMAT 0190-03672 可控硅功率控制器是半导体设备中用于精确调节加热功率的核心组件，设计上侧重控制精度与系统兼容性。
中间（15条特点）
采用SCR可控硅技术，控制精度高。
支持相位角和过零触发两种控制方式。
单相最大承载电流约30A。
适配AMAT主流半导体设备平台。
支持电压、电流、功率闭环反馈。
接受4-20mA或0-10V标准模拟信号控制。
集成过流、过压、过热保护功能。
具备缺相及负载短路保护。
强弱电采用光电隔离，抗干扰强。
部分型号支持RS-485通讯接口。
采用强制风冷散热，内置温控风扇。
面板带状态指示灯，便于故障诊断。
工作温度范围0℃至+55℃。
采用19英寸机架式安装，结构紧凑。
无触点开关设计，使用寿命长。
结尾
总体而言，AMAT 0190-03672 是一款性能稳定、保护全面的功率控制器，能够满足半导体设备对加热功率控制的严格要求。
AMAT 0190-03672 thyristor power controller is a core component used in semiconductor equipment for precise adjustment of heating power, with a focus on control accuracy and system compatibility in design.
Middle (15 characteristics)
Adopting SCR thyristor technology, the control accuracy is high.
Supports two control modes: phase angle and zero crossing trigger.
The maximum carrying current of a single-phase is about 30A.
Adapt to AMAT's mainstream semiconductor equipment platform.
Support voltage, current, and power closed-loop feedback.
Accept 4-20mA or 0-10V standard analog signal control.
Integrated overcurrent, overvoltage, and overheat protection functions.
Equipped with phase loss and load short circuit protection.
Strong and weak electricity are isolated by optoelectronics, with strong anti-interference ability.
Some models support RS-485 communication interface.
Adopting forced air cooling and built-in temperature controlled fan for heat dissipation.
The panel is equipped with status indicator lights for easy fault diagnosis.
The working temperature range is from 0 ℃ to+55 ℃.
Adopting a 19 inch rack mounted installation, the structure is compact.
Contactless switch design, long service life.
ending
Overall, AMAT 0190-03672 is a power controller with stable performance and comprehensive protection, which can meet the strict requirements of semiconductor equipment for heating power control.
