VMIC 332-000234-001E 印刷电路板 PDF资料
1.产 品 资 料 介 绍：
VMIC 332-000234-001E 印刷电路板产品特点
VMIC 332-000234-001E 是原通用电气工业自动化部门旗下 VMIC 系列的一款 VMEbus 单板计算机，完整型号通常标识为 VMIVME-7588，现由 Abaco Systems 继续生产。其主要特点如下：
搭载英特尔奔腾 III 系列处理器，数据处理能力较强。
配备 128 MB 板载内存，满足工业控制需求。
提供 256 KB 二级缓存，采用双独立总线架构。
采用英特尔 855GME 芯片组，集成 I/O 控制器。
符合 VME64x 标准，支持标准 VME P1 和 P2 连接器。
集成 100 Mbit 以太网端口，支持网络通信。
配备 RS-232 串口和 USB 接口。
集成双通道 Ultra160 SCSI 控制器，可连接高速存储设备。
板载闪存，支持软盘和硬盘存储。
包含实时时钟、中断控制器和看门狗定时器。
符合标准 VME Eurocard 模块尺寸，适配标准机箱。
支持 -20℃ 至 +70℃ 宽温工作范围。
支持 VMEbus 标准电源供电（+5V、+12V、-12V DC）。
适用于国防、工业控制、航空航天等高可靠性场景。
可作为同系列老旧控制板的替换备件。
综上，VMIC 332-000234-001E 是一款基于 VMEbus 架构的高性能单板计算机，适用于对可靠性和实时性要求较高的工业及国防领域
VMIC 332-000234-001E 印刷电路板 英文介绍
VMIC 332-000234-001E Printed Circuit Board Product Features
VMIC 332-000234-001E is a VMEbus single board computer from the VMIC series under the former General Electric Industrial Automation Department. The complete model is usually labeled as VMIVME-7588 and is currently being produced by Abaco Systems. Its main characteristics are as follows:
Equipped with Intel Pentium III series processors, it has strong data processing capabilities.
Equipped with 128 MB onboard memory to meet industrial control requirements.
Provide 256 KB L2 cache and adopt a dual independent bus architecture.
Adopting Intel 855GME chipset, integrated I/O controller.
Compliant with VME64x standard, supporting standard VME P1 and P2 connectors.
Integrated 100 Mbit Ethernet port, supporting network communication.
Equipped with RS-232 serial port and USB interface.
Integrated dual channel Ultra160 SCSI controller, capable of connecting high-speed storage devices.
Onboard flash memory, supporting both floppy and hard disk storage.
Includes real-time clock, interrupt controller, and watchdog timer.
Meets the standard VME Eurocard module size and is compatible with standard chassis.
Supports a wide temperature range of -20 ℃ to+70 ℃.
Supports VMEbus standard power supply (+5V,+12V, -12V DC).
Suitable for high reliability scenarios such as national defense, industrial control, aerospace, etc.
Can be used as a replacement spare part for old control boards in the same series.
Overall, VMIC 332-000234-001E is a high-performance single board computer based on the VMEbus architecture, suitable for industrial and defense fields that require high reliability and real-time performance
VMIC 332-000234-001E 印刷电路板 产品图片
