5PC900.TS17-02 CPU 控制主板 PDF资料
1.产 品 资 料 介 绍：
5PC900.TS17-02 CPU控制主板产品特点
5PC900.TS17-02 是贝加莱 APC910 系列的一款 CPU 控制主板，搭载英特尔赛扬处理器，适用于工业自动化控制场景。其主要特点如下：
搭载英特尔赛扬 G3900E 双核处理器，主频 2.4 GHz。
采用 14 纳米制程，集成 HD Graphics 510 显示核心。
配备 HM170 芯片组，支持 DDR4 内存，最大 32 GB。
支持 TPM 2.0 安全模块，增强系统安全性。
支持 DVI、RGB 和 DisplayPort 多种显示输出，最高 4K。
提供 4 个 SATA 接口，可连接硬盘或 SSD。
支持英特尔虚拟化技术（VT-x 和 VT-d）。
符合工业级 EN 61131-2 环境标准。
支持 Automation Studio V4.3 及以上版本编程组态。
可选主动或被动散热套件，按需配置。
被动散热时主频降至 1.7 GHz，主动散热可全速 2.4 GHz。
通过 CE、UKCA 和 cULus 等多项国际认证。
专为 APC910 系列工业 PC 设计，适配性好。
支持模块化扩展，方便系统升级。
面向长期可用性和高可靠性要求的工业场景。
总之，5PC900.TS17-02 是一款性能实用、接口丰富且可靠性高的工业控制主板，适合作为 APC910 平台的核心计算与控制单元。
5PC900.TS17-02 CPU Control Motherboard Product Features
5PC900.TS17-02 is a CPU control motherboard from the B&R APC910 series, equipped with Intel Celeron processors, suitable for industrial automation control scenarios. Its main characteristics are as follows:
Equipped with Intel Celeron G3900E dual core processor, with a clock speed of 2.4 GHz.
Adopting a 14 nanometer process and integrating HD Graphics 510 display core.
Equipped with HM170 chipset, supporting DDR4 memory, with a maximum capacity of 32 GB.
Support TPM 2.0 security module to enhance system security.
Supports multiple display outputs including DVI, RGB, and DisplayPort, up to 4K.
Provide 4 SATA interfaces for connecting hard drives or SSDs.
Supports Intel virtualization technologies (VT-x and VT-d).
Compliant with the industrial grade EN 61131-2 environmental standard.
Support programming configuration for Automation Studio V4.3 and above versions.
Optional active or passive cooling kit, configured as needed.
When passive cooling is used, the main frequency drops to 1.7 GHz, while active cooling can operate at full speed of 2.4 GHz.
Obtained multiple international certifications such as CE, UKCA, and cULus.
Specially designed for APC910 series industrial PCs, with good adaptability.
Support modular expansion for easy system upgrades.
Targeting industrial scenarios that require long-term availability and high reliability.
In summary, 5PC900.TS17-02 is an industrial control motherboard with practical performance, rich interfaces, and high reliability, suitable as the core computing and control unit of APC910 platform.
