1769-L30ER 输入输出控制器 PDF资料
1.产 品 资 料 介 绍：
1769-L30ER 输入输出控制器产品特点
1769-L30ER 是罗克韦尔自动化 CompactLogix 5370 L3 系列的一款可编程自动化控制器，适用于中等规模的工业控制应用。其主要特点如下：
用户内存为1MB，满足中等级别控制需求。
附赠1GB SD卡，最大支持2GB，用于程序备份和固件更新。
配备双EtherNet/IP端口，支持设备级环网冗余，提升网络可靠性。
双端口内置交换机功能，简化环形或线性网络布线。
提供一个USB编程端口，方便现场调试和程序下载。
最多可连接16个EtherNet/IP节点，支持HMI、SCADA等设备通信。
支持最多8个本地1769 Compact I/O模块扩展。
支持最多32个任务，每个任务最多100个程序，多任务能力强。
控制器本身不带物理I/O点，需外接模块实现输入输出。
工作温度0至60℃，适应多数工业现场环境。
配有状态LED指示灯，方便快速诊断控制器运行状态。
是旧款1769-L31的升级替代品，内存更大且具备双网口。
支持100个虚拟轴控制，适用于对逻辑运算要求较高的场景。
通过cULus、CE、ATEX等多项国际认证，可用于危险环境。
需使用RSLogix 5000或Studio 5000软件（版本20以上）进行编程。
总之，1769-L30ER 在紧凑设计中集成了双以太网、充足内存和灵活的I/O扩展能力，是构建中低复杂度自动化控制系统的可靠选择。
1769-L30ER 输入输出控制器 英文介绍
Product Features of 1769-L30ER Input/Output Controller
1769-L30ER is a programmable automation controller in the Rockwell Automation CompactLogix 5370 L3 series, suitable for medium scale industrial control applications. Its main characteristics are as follows:
The user's memory is 1MB, which meets the requirements of medium level control.
Comes with a 1GB SD card, supporting up to 2GB, for program backup and firmware updates.
Equipped with dual EtherNet/IP ports, supporting device level ring network redundancy to enhance network reliability.
Dual port built-in switch function simplifies ring or linear network cabling.
Provide a USB programming port for easy on-site debugging and program download.
Up to 16 EtherNet/IP nodes can be connected, supporting communication between HMI, SCADA and other devices.
Supports up to 8 local 1769 Compact I/O module extensions.
Supports up to 32 tasks, with a maximum of 100 programs per task, and has strong multitasking capabilities.
The controller itself does not have physical I/O points and requires an external module to achieve input and output.
The working temperature ranges from 0 to 60 ℃, suitable for most industrial site environments.
Equipped with status LED indicator lights, it is convenient to quickly diagnose the operation status of the controller.
It is an upgraded replacement for the old 1769-L31, with larger memory and dual Ethernet ports.
Supports 100 virtual axis controls, suitable for scenarios with high requirements for logical operations.
Through multiple international certifications such as cULus, CE, ATEX, etc., it can be used in hazardous environments.
RSLogix 5000 or Studio 5000 software (version 20 or above) is required for programming.
In summary, the 1769-L30ER integrates dual Ethernet, ample memory, and flexible I/O expansion capabilities in a compact design, making it a reliable choice for building low to medium complexity automation control systems.
1769-L30ER 输入输出控制器 产品图片
