Xycom XVME-977磁盘驱动器板 PDF资料
1.产 品 资 料 介 绍：
Xycom XVME-977 磁盘驱动器板（存储接口控制模块）
Xycom XVME-977 是一款面向VMEbus工业系统设计的磁盘驱动器接口板，主要用于连接和管理各类存储设备，实现工业控制系统中的数据存储、读取与管理功能。
一、产品定位
XVME-977 属于存储控制与接口扩展模块，在系统中承担以下角色：
磁盘驱动器接口控制
数据存储管理
提供系统级数据访问通道
通常与CPU处理器卡配合使用，构建完整的数据存储子系统。
二、主要功能特点
多类型存储设备支持
支持连接多种磁盘设备，如：
硬盘驱动器（HDD）
软驱（FDD，早期系统）
磁带设备（部分配置）
标准接口集成
提供常见工业存储接口（如IDE/ATA或兼容接口），便于与不同存储设备对接。数据传输稳定可靠
通过VMEbus实现数据交互，保证数据读写的稳定性与一致性，适用于关键任务系统。系统引导支持
可作为系统启动设备接口，实现工业计算机的本地启动功能。工业级设计
具备良好的环境适应能力：
抗干扰能力强
适应长时间连续运行
支持工业现场复杂环境
Xycom XVME-977磁盘驱动器板 英文介绍
Xycom XVME-977 Disk Drive Board (Storage Interface Control Module)
Xycom XVME-977 is a disk drive interface board designed for VMEbus industrial systems, mainly used to connect and manage various storage devices, and achieve data storage, reading, and management functions in industrial control systems.
1、 Product positioning
XVME-977 belongs to the storage control and interface expansion module, which plays the following roles in the system:
Disk drive interface control
Data storage management
Provide system level data access channels
Usually used in conjunction with CPU processor cards to build a complete data storage subsystem.
2、 Main functional features
Multi type storage device support
Supports connecting multiple disk devices, such as:
Hard Disk Drive (HDD)
Soft drive (FDD, early system)
Magnetic tape equipment (partial configuration)
Standard interface integration
Provide common industrial storage interfaces (such as IDE/ATA or compatible interfaces) for easy integration with different storage devices.
Stable and reliable data transmission
Implementing data exchange through VMEbus ensures stability and consistency in data reading and writing, making it suitable for critical task systems.
System guidance support
Can serve as an interface for system startup devices, enabling local startup functionality for industrial computers.
Industrial-grade design
Having good adaptability to the environment:
Strong anti-interference ability
Adapt to long-term continuous operation
Supporting complex industrial environments on site
