XYCOM XVME-661处理器模块 PDF资料
1.产 品 资 料 介 绍：
XYCOM XVME-661 处理器模块介绍
XYCOM XVME-661 是一款高性能 VMEbus 架构单板计算机（SBC）处理器模块，适用于工业自动化、嵌入式控制和数据处理系统。该模块在继承 XVME-660 高可靠性的基础上，进一步提升了处理能力与系统扩展性，能够胜任复杂控制和实时运算任务。
一、产品概述
XVME-661 采用 Intel 嵌入式处理器架构（如低功耗 Pentium 或同级 CPU），支持 PC/AT 兼容环境。模块可作为 VME 系统的核心 CPU 单元，提供高性能运算、系统控制以及多任务管理功能，适用于工业级长时间连续运行场景。
二、产品特点
高性能处理器
配备 Intel Pentium 级或同类处理器，主频约 1.5GHz～2.0GHz，处理能力强，满足复杂运算和实时控制需求。大容量内存支持
板载 DDR 内存可达 1GB，可选 ECC 校验，确保系统数据可靠性与稳定性。VME总线全面兼容
支持 VME64 标准，包括 A32/A24/A16 地址空间和 D64/D32 数据传输模式，具备总线主控和从控功能。PC/AT兼容架构
支持多种工业操作系统，方便软件开发、移植和系统升级。多种接口支持
提供串口、USB、并行接口及视频输出接口，适合人机界面及外围设备连接。无头运行模式
支持串口控制，可在无显示设备环境下进行系统配置和管理，适合嵌入式应用。高速缓存设计
内置二级缓存，优化数据访问速度，提高整体系统性能。工业级稳定性设计
抗干扰能力强，支持宽温度工作环境，可长期稳定运行。单槽紧凑结构
单槽 VME 模块设计，节省系统空间，便于系统集成与维护。
XYCOM XVME-661处理器模块 英文介绍
Introduction to XYCOM XVME-661 Processor Module
XYCOM XVME-661 is a high-performance VMEbus architecture single board computer (SBC) processor module suitable for industrial automation, embedded control, and data processing systems. On the basis of inheriting the high reliability of XVME-660, this module further enhances its processing capability and system scalability, and is capable of handling complex control and real-time computing tasks.
1、 Product Overview
XVME-661 adopts Intel embedded processor architecture (such as low-power Pentium or equivalent CPU) and supports PC/AT compatible environments. The module can serve as the core CPU unit of the VME system, providing high-performance computing, system control, and multitasking management functions, suitable for industrial level long-term continuous operation scenarios.
2、 Product Features
High performance processor
Equipped with Intel Pentium class or similar processors, with a clock speed of approximately 1.5GHz to 2.0GHz, strong processing power, meeting complex computing and real-time control requirements.
Large capacity memory support
The onboard DDR memory can reach 1GB, with optional ECC verification to ensure system data reliability and stability.
VME bus is fully compatible
Supports VME64 standard, including A32/A24/A16 address space and D64/D32 data transfer mode, with bus master and slave functions.
PC/AT compatible architecture
Supports multiple industrial operating systems, facilitating software development, porting, and system upgrades.
Multiple interface support
Provide serial port USB、 Parallel interface and video output interface, suitable for human-machine interface and peripheral device connection.
Headless operation mode
Supports serial port control, allowing system configuration and management in environments without display devices, suitable for embedded applications.
Cache Design
Built in second level cache optimizes data access speed and improves overall system performance.
Industrial grade stability design
Strong anti-interference ability, supports wide temperature working environment, and can operate stably for a long time.
Single slot compact structure
Single slot VME module design saves system space and facilitates system integration and maintenance.
