MVI56-DH485可编程通讯模块 PDF资料
1.产 品 资 料 介 绍：
MVI56-DH485 可编程通讯模块是一种工业自动化通信接口模块，用于在控制系统与现场设备之间建立稳定的数据通信通道。该模块由ProSoft Technology设计开发，能够支持工业网络中的数据交换与协议通信，使控制系统能够接入不同类型的工业设备，实现系统互联和数据共享。
产品特点：
支持DH-485工业通信网络协议，适用于工业设备互联。
具备可编程通信功能，可根据系统需求进行灵活配置。
内置高速通信处理器，提高数据处理效率。
提供稳定的数据缓冲区，保证通信过程连续可靠。
支持多节点设备连接，便于构建工业网络结构。
模块结构紧凑，适合工业控制机架安装。
具备运行状态指示功能，方便设备监控与维护。
抗干扰能力强，可在复杂工业环境中稳定运行。
技术参数：
通信协议：DH-485网络协议
通信接口：串行通信端口
数据传输速率：最高115.2 kbps
供电方式：由控制系统背板供电
工作温度范围：0℃～60℃
安装方式：机架式安装
应用领域：
MVI56-DH485可编程通讯模块广泛应用于工业自动化控制系统，如生产线自动化控制、设备数据采集系统、能源管理系统、过程控制系统以及大型设备监控网络。通过该模块，控制器能够与工业仪表、传感器、驱动设备及其他自动化设备进行可靠通信。
MVI56-DH485可编程通讯模块 英文介绍
The MVI56-DH485 programmable communication module is an industrial automation communication interface module used to establish a stable data communication channel between control systems and field devices. This module is designed and developed by ProSoft Technology, which can support data exchange and protocol communication in industrial networks, enabling control systems to access different types of industrial equipment and achieve system interconnection and data sharing.
Product Features:
Support DH-485 industrial communication network protocol, suitable for industrial equipment interconnection.
It has programmable communication function and can be flexibly configured according to system requirements.
Built in high-speed communication processor to improve data processing efficiency.
Provide a stable data buffer to ensure continuous and reliable communication processes.
Support multi node device connections, facilitating the construction of industrial network structures.
The module structure is compact and suitable for industrial control rack installation.
Equipped with operational status indication function, convenient for equipment monitoring and maintenance.
Strong anti-interference ability, capable of stable operation in complex industrial environments.
Technical Specifications:
Communication Protocol: DH-485 Network Protocol
Communication interface: serial communication port
Data transmission rate: up to 115.2 kbps
Power supply mode: Powered by the control system backplane
Working temperature range: 0 ℃~60 ℃
Installation method: Rack mounted installation
Application fields:
The MVI56-DH485 programmable communication module is widely used in industrial automation control systems, such as production line automation control, equipment data acquisition systems, energy management systems, process control systems, and large-scale equipment monitoring networks. Through this module, the controller can reliably communicate with industrial instruments, sensors, drive equipment, and other automation devices.
