MVI56-103M通信模块 PDF资料
1.产 品 资 料 介 绍：
MVI56-103M 通信模块是一款工业自动化网络接口模块，专为 MicroLogix 和 CompactLogix 控制系统设计。该模块主要用于 PLC 与现场设备、控制器或上位系统之间的数据交换，支持多种工业串行通信协议，实现工业系统内可靠的远程数据传输。
主要功能特点：
支持多种工业串行通信协议，包括 DF1 和 Modbus RTU，可兼容不同厂商的设备。
模块可作为主站或从站使用，灵活适应各种网络拓扑。
内置数据缓冲和错误检测功能，保证通信数据的完整性与可靠性。
可通过 PLC 背板与控制器高速数据交换，实现实时数据采集和控制。
提供通信状态指示灯，便于监控模块运行状态和排查故障。
模块结构紧凑，支持机架插入式安装，方便维护和更换。
典型技术参数：
型号：MVI56-103M
模块类型：串行通信模块
适用平台：MicroLogix / CompactLogix
串行接口：RS232 / RS485
最大通信速率：115.2 kbps
支持设备数：每通道最多 32 个设备
电源消耗：约 2 W
工作温度：0℃ ～ 60℃
存储温度：-40℃ ～ 85℃
相对湿度：5% ～ 95%（无冷凝）
应用领域：
MVI56-103M 通信模块广泛应用于工业自动化与过程控制系统，例如电力系统、石化装置、制造生产线、能源管理系统以及水处理控制系统。它能够实现 PLC 与现场仪表、传感器或上位控制系统之间的可靠串行通信，确保数据传输准确、高效，并提升系统的自动化水平和维护便利性。
MVI56-103M通信模块 英文介绍
The MVI56-103M communication module is an industrial automation network interface module designed specifically for MicroLogix and CompactLogix control systems. This module is mainly used for data exchange between PLC and field devices, controllers or upper level systems, supporting multiple industrial serial communication protocols to achieve reliable remote data transmission within industrial systems.
Main functional features:
Supports multiple industrial serial communication protocols, including DF1 and Modbus RTU, and is compatible with devices from different manufacturers.
Modules can be used as master or slave stations, flexibly adapting to various network topologies.
Built in data buffering and error detection functions ensure the integrity and reliability of communication data.
Real time data acquisition and control can be achieved through high-speed data exchange between the PLC backplane and the controller.
Provide communication status indicator lights for monitoring module operation status and troubleshooting.
The module structure is compact and supports rack insertion installation, making maintenance and replacement convenient.
Typical technical parameters:
Model: MVI56-103M
Module type: Serial communication module
Applicable platforms: MicroLogix/CompactLogix
Serial interface: RS232/RS485
Maximum communication speed: 115.2 kbps
Number of supported devices: up to 32 devices per channel
Power consumption: approximately 2 W
Working temperature: 0 ℃~60 ℃
Storage temperature: -40 ℃~85 ℃
Relative humidity: 5% to 95% (without condensation)
Application fields:
The MVI56-103M communication module is widely used in industrial automation and process control systems, such as power systems, petrochemical plants, manufacturing production lines, energy management systems, and water treatment control systems. It can achieve reliable serial communication between PLC and field instruments, sensors or upper control systems, ensuring accurate and efficient data transmission, and improving the automation level and maintenance convenience of the system.
