KJ4003X1-BE1垂直右侧扩展器 PDF资料
1.产 品 资 料 介 绍：
KJ4003X1-BE1 垂直右侧扩展器 是 Emerson Electric 旗下 DeltaV 系统中的结构扩展组件，属于 Vertical 系列右侧扩展载体，用于系统模块容量的延伸与安装扩展。
一、产品定位
KJ4003X1-BE1 属于右侧扩展器（Right-side Extender），主要安装在已有垂直托架的右侧，用于增加模块安装空间。
它不参与控制运算或信号处理，而是用于扩展系统结构布局。
二、结构特点
右侧扩展设计
专为垂直载板右侧连接设计，安装结构匹配度高。模块容量扩展
可增加 I/O 模块或相关单元的安装位置，提高系统集成密度。工业级机械结构
金属支撑框架，具备良好的抗振动和耐环境性能。系统兼容性强
与 DeltaV Vertical 托架及相关载板系列配套使用。
三、应用场景
需要增加 I/O 点数的控制柜
生产线扩容改造项目
大型流程工业 DCS 系统扩展
电力、石化、能源自动化控制系统
四、应用优势
支持系统后期扩展，提升灵活性
模块排列规范，维护便捷
安装结构标准化，便于升级
有助于优化机柜空间布局
总结
KJ4003X1-BE1 垂直右侧扩展器是 DeltaV 系统中用于结构扩容的重要组件，能够在保持系统稳定性的前提下，实现模块安装空间的灵活扩展，特别适用于中大型自动化控制系统的升级与扩展应用。
KJ4003X1-BE1垂直右侧扩展器 英文介绍
KJ4003X1-BE1 Vertical Right Side Expander is a structural expansion component in Emerson Electric's DeltaV system, belonging to the Vertical series right side expansion carrier, used for extending and installing system module capacity.
1、 Product positioning
KJ4003X1-BE1 belongs to the Right side extender, mainly installed on the right side of existing vertical brackets to increase module installation space.
It does not participate in control operations or signal processing, but is used to expand the system architecture layout.
2、 Structural characteristics
Right side expansion design
Specially designed for vertical carrier board connection on the right side, with high compatibility of installation structure.
Module capacity expansion
The installation position of I/O modules or related units can be increased to improve the system integration density.
Industrial grade mechanical structure
Metal support frame, with good anti vibration and environmental resistance performance.
High compatibility
Used in conjunction with the DeltaV Vertical bracket and related carrier series.
3、 Application scenarios
Control cabinet that requires an increase in I/O points
Production line expansion and renovation project
Expansion of DCS systems in large-scale process industries
Power, petrochemical, and energy automation control systems
4、 Application advantages
Support system expansion in the later stage to enhance flexibility
Standardized module arrangement, easy maintenance
Standardized installation structure for easy upgrading
Helps optimize cabinet space layout
summary
The KJ4003X1-BE1 vertical right extender is an important component used for structural expansion in the DeltaV system. It can flexibly expand module installation space while maintaining system stability, and is particularly suitable for upgrading and expanding applications of medium and large automation control systems.
