KJ1710X1-BA1单端口纤维开关 PDF资料
1.产 品 资 料 介 绍：
KJ1710X1-BA1 是 Emerson DeltaV 分布式控制系统中的单端口光纤开关，用于工业控制网络中实现光纤通信的接口与桥接。它主要用于将控制网络与光纤链路连接，提升通信距离和抗干扰能力。
一、模块定位
用于 DeltaV 系统中，将光纤链路与控制网络接口连接。
适合远程机柜或控制节点，确保控制器与 I/O 模块之间的数据稳定传输。
属于控制系统网络基础设施模块，不直接参与控制逻辑。
二、主要功能
单端口光纤连接
提供一个光纤端口，与其他光纤设备建立通信链路，提高远距离数据传输稳定性。网络桥接
在光纤与以太网控制网络之间实现物理层桥接，使控制系统各节点协同通信。工业级可靠性
模块适应宽温度范围、抗振动和抗冲击的工业环境，确保现场长期稳定运行。
三、典型技术特点
工作电压：直流供电（约19–28 V DC）
工作电流：约 250 mA DC
温度范围：-40°C 至 +70°C
安装方式：机柜或导轨安装
抗振动、抗冲击能力：符合工业级标准
四、应用场景
控制站与远程节点间的光纤通信
网络拓扑跨机柜或远程现场节点的桥接
高干扰、电磁复杂环境下的数据传输
分布式控制系统网络可靠性提升
KJ1710X1-BA1单端口纤维开关 英文介绍
KJ1710X1-BA1 is a single port fiber optic switch in Emerson DeltaV distributed control systems, used as an interface and bridge for fiber optic communication in industrial control networks. It is mainly used to connect control networks with fiber optic links, improving communication distance and anti-interference capabilities.
1、 Module positioning
Used in DeltaV systems to connect fiber optic links to control network interfaces.
Suitable for remote cabinets or control nodes, ensuring stable data transmission between controllers and I/O modules.
Belonging to the network infrastructure module of the control system, it does not directly participate in the control logic.
2、 Main functions
Single port fiber optic connection
Provide a fiber optic port to establish communication links with other fiber optic devices, improving the stability of long-distance data transmission.
Internet Bridge
Implement physical layer bridging between fiber optic and Ethernet control networks to enable collaborative communication among control system nodes.
Industrial grade reliability
The module is suitable for industrial environments with a wide temperature range, vibration resistance, and impact resistance, ensuring long-term stable operation on site.
3、 Typical technical features
Working voltage: DC power supply (approximately 19-28V DC)
Working current: approximately 250 mA DC
Temperature range: -40 ° C to+70 ° C
Installation method: Cabinet or rail installation
Anti vibration and anti impact capability: meets industrial grade standards
4、 Application scenarios
Fiber optic communication between control station and remote nodes
Network topology bridging across cabinets or remote field nodes
Data transmission in high interference and complex electromagnetic environments
Improving the reliability of distributed control system networks
