ASSOCIATED RESEARCH 7564SA 分析仪 PDF资料

1.产 品 资 料 介 绍：

ASSOCIATED RESEARCH 7564SA 分析仪，其产品特点可归纳如下：

属于Quadcheck II系列电气安全合规分析仪。

集成AC耐压、DC耐压、绝缘电阻和接地导通四种测试功能于一体。

AC耐压输出5kV，DC耐压输出6kV。

接地导通测试电流3A至30A，电阻测量范围0至600mΩ。

单次连接即可完成全部测试，操作简便。

可选配GPIB、RS-232或打印机接口，便于数据输出。

可选配扫描器，实现多通道扩展测试。

采用专利电路技术，提升直流测试效率和安全性。

可存储50组测试程序，每组最多8个步骤。

配备2×20字符LCD显示屏，清晰显示测试数据。

符合UL、CSA、IEC等国际安全标准。

尺寸432×147×515mm，重约24kg，适合机柜安装。

前面板可调节蜂鸣器音量和LCD对比度。

可与其他测试设备互联，构建完整测试系统。

可选配8端口高压扫描卡，实现多路测试。

综上所述，ASSOCIATED RESEARCH 7564SA 是一款四合一电气安全合规分析仪，适用于生产线与实验室的安规测试场景。选型或替换时建议参考原厂手册确认配件兼容性。

ASSOCIATED RESEARCH 7564SA 分析仪 英文介绍

The product features of the ASSOCIATED RESEARCH 7564SA analyzer can be summarized as follows:

It belongs to the Quadcheck II series electrical safety compliance analyzer.

Integrate four testing functions: AC withstand voltage, DC withstand voltage, insulation resistance, and grounding continuity.

AC withstand voltage output 5kV, DC withstand voltage output 6kV.

The grounding continuity test current is 3A to 30A, and the resistance measurement range is 0 to 600m Ω.

All tests can be completed with a single connection, and the operation is simple.

Optional GPIB, RS-232, or printer interfaces for easy data output.

Optional scanner for multi-channel expansion testing.

Adopting patented circuit technology to enhance the efficiency and safety of DC testing.

It can store 50 sets of test programs, with a maximum of 8 steps per set.

Equipped with a 2x20 character LCD display screen, the test data is clearly displayed.

Compliant with international safety standards such as UL, CSA, IEC, etc.

Dimensions 432 × 147 × 515mm, weighing approximately 24kg, suitable for cabinet installation.

The front panel can adjust the buzzer volume and LCD contrast.

Can be interconnected with other testing equipment to build a complete testing system.

Optional 8-port high-voltage scanning card for multi-channel testing.

In summary, ASSOCIATED RESEARCH 7564SA is a four in one electrical safety compliance analyzer suitable for safety testing scenarios in production lines and laboratories. It is recommended to refer to the original factory manual to confirm the compatibility of accessories when selecting or replacing.

ASSOCIATED RESEARCH 7564SA 分析仪 产品图片
