INFRANOR EASY-AK-230/17 伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
INFRANOR EASY-AK-230/17 是 Infranor 公司 XtrapulsEasy 系列的一款全数字伺服驱动器，采用正弦波 PWM 控制技术，专为驱动无刷交流伺服电机设计，以高性价比和易用性著称。以下是该型号的核心特点与应用领域：
产品特点
全数字正弦波 PWM 控制，实现精准驱动。
支持旋转变压器、增量式编码器、霍尔传感器及无传感器等多种反馈模式。
提供 CANopen 总线、±10V 模拟量及独立 I/O 逻辑等多种控制接口。
配备 24V 辅助逻辑供电，断电后可保持位置信息。
具备软启动功能，限制上电浪涌电流。
通过配置软件可进行参数设置，支持自整定与自动相位检测。
内置电流、速度、位置三环控制，采样周期 0.5ms。
紧凑模块化设计，集成短路、过压等保护功能。
应用领域
CANopen 总线控制的多轴运动系统。
独立 I/O 触发的单轴运动任务。
±10V 模拟量速度控制与位置反馈输出。
工业机器人关节的伺服驱动。
数控机床的进给轴与主轴驱动。
自动化生产线中的物料搬运与定位。
包装机械、纺织机械等通用自动化设备。
对成本敏感的基础伺服应用场合。
结尾
综上所述，INFRANOR EASY-AK-230/17 凭借灵活的接口配置、多样的反馈选项和便捷的调试功能，为工业自动化设备提供了一个可靠且易于集成的伺服驱动解决方案。
INFRANOR EASY-AK-230/17 伺服驱动器 英文介绍
INFRANOR EASY-AK-230/17 is a fully digital servo drive from Infranor's XtrapulsEasy series, which uses sine wave PWM control technology and is designed specifically for driving brushless AC servo motors. It is known for its high cost-effectiveness and ease of use. The following are the core features and application areas of this model:
Product Features
Fully digital sine wave PWM control for precise driving.
Supports multiple feedback modes such as rotary transformers, incremental encoders, Hall sensors, and sensorless.
Provide various control interfaces such as CANopen bus, ± 10V analog, and independent I/O logic.
Equipped with 24V auxiliary logic power supply, it can maintain position information after power failure.
Equipped with soft start function to limit surge current during power on.
Parameter settings can be made through configuration software, supporting self-tuning and automatic phase detection.
Built in current, speed, and position three loop control, with a sampling period of 0.5ms.
Compact modular design, integrating protection functions such as short circuit and overvoltage.
Application Domain
Multi axis motion system controlled by CANopen bus.
Single axis motion tasks triggered by independent I/O.
± 10V analog speed control and position feedback output.
Servo drive of industrial robot joints.
The feed axis and spindle drive of CNC machine tools.
Material handling and positioning in automated production lines.
General automation equipment such as packaging machinery and textile machinery.
For cost sensitive basic servo applications.
ending
In summary, INFRANOR EASY-AK-230/17 provides a reliable and easy to integrate servo drive solution for industrial automation equipment with flexible interface configuration, diverse feedback options, and convenient debugging functions.
INFRANOR EASY-AK-230/17 伺服驱动器 产品图片
