Philips 453567006481 采集板 PDF资料
1.产 品 资 料 介 绍：
PHILIPS 型号 453567006481 采集板，是一款用于医疗影像设备（如CT或X射线系统）的信号采集与数字化前端板卡，具备以下特点：
采用高精度模数转换器（ADC），采样分辨率高。
多通道并行采集架构，支持阵列式探测器信号输入。
输入噪声极低，有效提升微弱信号捕获能力。
采样时钟低抖动设计，确保相位一致性。
内置可编程增益放大器（PGA），适配不同信号幅度。
板载数字滤波功能，有效抑制外界干扰杂波。
高速串行数据输出接口（如LVDS），带宽充足。
电源管理单元设计完善，各供电轨独立稳压。
关键器件选用医疗级规格，寿命长可靠性高。
PCB采用阻抗匹配走线，保障信号完整性。
板载温度传感器，监测工作温度并反馈系统。
紧凑型布局，适应设备内部有限空间安装。
接插件选用高可靠性型号，抗震防松脱。
出厂经图像质量及功能全检，品质有保障。
兼容PHILIPS配套影像系统，更换维护便捷。
结尾
综上，PHILIPS 453567006481 采集板以高精度采集、低噪声处理和稳定的数据传输为核心优势，为医疗成像设备提供可靠的信号前端支持。
PHILIPS model 453567006481 acquisition board is a signal acquisition and digitization front-end board used for medical imaging equipment (such as CT or X-ray systems), with the following characteristics:
Adopting high-precision analog-to-digital converter (ADC) with high sampling resolution.
Multi channel parallel acquisition architecture, supporting array detector signal input.
The input noise is extremely low, effectively improving the ability to capture weak signals.
The sampling clock is designed with low jitter to ensure phase consistency.
Built in programmable gain amplifier (PGA), adaptable to different signal amplitudes.
Onboard digital filtering function effectively suppresses external interference clutter.
High speed serial data output interface (such as LVDS) with sufficient bandwidth.
The design of the power management unit is complete, and each power supply rail is independently stabilized.
The key components are selected with medical grade specifications, which have a long lifespan and high reliability.
The PCB adopts impedance matching wiring to ensure signal integrity.
Onboard temperature sensor, monitoring operating temperature and providing feedback to the system.
Compact layout, suitable for installation in limited internal space of equipment.
The connectors are selected with high reliability models that are earthquake resistant and anti loosening.
After undergoing a comprehensive inspection of image quality and functionality at the factory, the quality is guaranteed.
Compatible with PHILIPS supporting imaging system, easy to replace and maintain.
ending
In summary, the PHILIPS 453567006481 acquisition board has the core advantages of high-precision acquisition, low-noise processing, and stable data transmission, providing reliable signal front-end support for medical imaging equipment.
