arroyo instruments  5300-08-24-ND 控制器模块  PDF资料

1.产 品 资 料 介 绍：

Arroyo Instruments 型号 5300-08-24-ND 控制器模块，是一款面向激光二极管驱动与精密温控应用的高性能集成模块，具备以下特点：

1. 采用低噪声线性驱动设计，输出纹波极低。

2. 支持恒流（CC）与恒功率（CP）双模式输出。

3. 内置精密TEC控制回路，温控稳定性优于±0.01°C。

4. 输出电流范围适配中小功率激光负载需求。

5. 电压自适应调整，有效降低模块内部功耗。

6. 支持外部模拟调制输入，便于动态功率调节。

7. 具备软启动与输出缓升功能，防止浪涌损坏负载。

8. 多重保护机制：过流、过压、反接及瞬态抑制。

9. 高精度ADC实时回读电流、电压及温度数值。

10. 通讯接口支持USB及RS-232，方便上位机集成。

11. 前面板OLED显示屏，参数读取直观清晰。

12. 按键式操作面板，支持本地参数设定与保存。

13. 紧凑型金属机壳设计，利于散热且屏蔽干扰。

14. 兼容标准19英寸机架安装，适用于系统集成。

15. 出厂经全面校准与老化测试，长期稳定性优异。

结尾
综上，Arroyo Instruments 5300-08-24-ND 控制器模块以低噪声驱动、精密温控和丰富接口为核心优势，适用于光电子器件测试与精密科研实验场景。

arroyo instruments  5300-08-24-ND 控制器模块  英文介绍

Arroyo Instruments model 5300-08-24-ND controller module is a high-performance integrated module designed for laser diode driving and precision temperature control applications, featuring the following features:

Adopting a low-noise linear drive design, the output ripple is extremely low.

Supports dual-mode output of constant current (CC) and constant power (CP).

Built in precision TEC control circuit, with temperature stability better than ± 0.01 ° C.

The output current range is suitable for small and medium power laser load requirements.

Voltage adaptive adjustment effectively reduces internal power consumption of the module.

Support external analog modulation input for dynamic power regulation.

Equipped with soft start and output ramp up function to prevent surge damage to the load.

Multiple protection mechanisms: overcurrent, overvoltage, reverse connection, and transient suppression.

High precision ADC real-time reads back current, voltage, and temperature values.

The communication interface supports USB and RS-232, making it convenient for upper computer integration.

The front panel OLED display screen provides intuitive and clear parameter reading.

Button based operation panel, supporting local parameter setting and saving.

Compact metal casing design, conducive to heat dissipation and shielding interference.

Compatible with standard 19 inch rack installation, suitable for system integration.

After comprehensive calibration and aging testing at the factory, it has excellent long-term stability.

ending

In summary, the Arroyo Instruments 5300-08-24-ND controller module has the core advantages of low-noise driving, precision temperature control, and rich interfaces, making it suitable for optoelectronic device testing and precision scientific research experimental scenarios.

arroyo instruments  5300-08-24-ND 控制器模块  产品图片
