Sanritz Automation SVP501-3-P10 信号板卡 PDF资料
1.产 品 资 料 介 绍：
Sanritz Automation SVP501-3-P10 信号板卡，其产品特点可归纳如下：
属于Sanritz Automation生产的处理器PCB卡，是设备中的核心控制板卡。
可集成于DNS（Dainippon Screen）FC-3000湿法工作站的系统中。
型号中的“P10”表明其作为子板，与主板配合使用。
采用工业级多层PCB设计，具备良好的信号完整性和抗干扰性能。
在设备控制系统中承担信号采集、分配与转换功能。
作为主控板与传感器、执行器等下级模块之间的连接桥梁。
可实现不同模块间的电平转换与电气隔离保护。
负责将主控指令传输至阀门、加热器、泵等执行元件。
回传工艺腔体内温度、液位、压力等传感器数据至主控单元。
分配来自电源模块的稳定电压至各子模块。
搭载逻辑元件、电平转换器或微控制器，辅助执行底层控制逻辑。
通过背板连接器或扁平排线与其他模块实现物理连接。
应用于半导体湿法清洗、刻蚀等工艺设备。
适配DNS FC-3000等设备平台的控制子系统。
该信号板卡在二手市场有流通，表明其具备一定的可替换性。
综上所述，Sanritz Automation SVP501-3-P10 是一款用于DNS半导体湿法设备的专用信号处理板卡，承担信号采集、转换与分配功能，适用于FC-3000等设备平台的控制系统
Sanritz Automation SVP501-3-P10 信号板卡 英文介绍
The product features of Sanritz Automation SVP501-3-P10 signal board can be summarized as follows:
The processor PCB card produced by Sanritz Automation is the core control board in the equipment.
Can be integrated into the DNS (Dainippon Screen) FC-3000 wet workstation system.
The "P10" in the model indicates that it is used as a daughter board in conjunction with the motherboard.
Adopting industrial grade multi-layer PCB design, it has good signal integrity and anti-interference performance.
Undertake signal acquisition, distribution, and conversion functions in the device control system.
As a connecting bridge between the main control board and subordinate modules such as sensors and actuators.
It can achieve level conversion and electrical isolation protection between different modules.
Responsible for transmitting main control instructions to executing components such as valves, heaters, pumps, etc.
Return temperature, liquid level, pressure and other sensor data from the process chamber to the main control unit.
Allocate stable voltage from the power module to each submodule.
Equipped with logic components, level converters, or microcontrollers to assist in executing underlying control logic.
Physical connection with other modules is achieved through backplane connectors or flat ribbon cables.
Applied to semiconductor wet cleaning, etching and other process equipment.
Control subsystem compatible with DNS FC-3000 and other device platforms.
The circulation of this signal board in the second-hand market indicates that it has a certain degree of replaceability.
In summary, Sanritz Automation SVP501-3-P10 is a dedicated signal processing board for DNS semiconductor wet process equipment, responsible for signal acquisition, conversion, and distribution functions, suitable for control systems on equipment platforms such as FC-3000
Sanritz Automation SVP501-3-P10 信号板卡 产品图片
