Matrox D1450-E4GB 显示器模块 PDF资料
1.产 品 资 料 介 绍：
Matrox D1450-E4GB 显示器模块，其产品特点可归纳如下：
属于Matrox D系列多屏显卡，专为视频墙和多显示器应用设计。
搭载定制GPU，配备4GB GDDR5显存。
配备4个HDMI 2.0输出接口，可同时驱动4台显示器。
支持单台最高4K分辨率（4096x2160 @ 60Hz）输出。
采用PCIe 3.0 x16总线接口，由主板插槽供电。
支持板对板帧锁定，最多同步4张显卡驱动16台显示器。
支持DirectX 12、OpenGL 4.5和OpenCL 1.2。
配套桌面管理软件，支持独立桌面、克隆、旋转等显示配置。
支持HDCP协议，可播放受保护内容。
可与采集卡或控制器配合，构建复杂视频墙系统。
主动散热设计，高负载下运行稳定。
尺寸20.137×12.697cm，全高单插槽设计。
典型功耗约47-50W，能效良好。
工作温度5-55℃，通过CE、FCC、RoHS认证。
提供三年保修，该型号已于2025年10月停产。
综上所述，Matrox D1450-E4GB是一款四路4K输出的专业多屏显卡，适用于视频墙、控制室等场景
The product features of Matrox D1450-E4GB display module can be summarized as follows:
Belonging to the Matrox D series multi screen graphics card, designed specifically for video wall and multi monitor applications.
Equipped with custom GPU and 4GB GDDR5 graphics memory.
Equipped with 4 HDMI 2.0 output interfaces, it can drive 4 monitors simultaneously.
Supports up to 4K resolution (4096x2160 @ 60Hz) output per unit.
Adopting PCIe 3.0 x16 bus interface, powered by motherboard slot.
Supports board to board frame locking, synchronizing up to 4 graphics cards to drive 16 monitors.
Supports DirectX 12, OpenGL 4.5, and OpenCL 1.2.
Supporting desktop management software, supporting independent desktop, cloning, rotation and other display configurations.
Supports HDCP protocol and can play protected content.
Can be used in conjunction with capture cards or controllers to build complex video wall systems.
Active heat dissipation design ensures stable operation under high loads.
Size 20.137 × 12.697cm, designed with a full height single slot.
Typical power consumption is about 47-50W, with good energy efficiency.
Working temperature range of 5-55 ℃, certified by CE, FCC, RoHS.
Providing a three-year warranty, this model was discontinued in October 2025.
In summary, Matrox D1450-E4GB is a professional multi screen graphics card with four 4K outputs, suitable for scenarios such as video walls and control rooms
