USHIO HB-50110AA OP1 电源模块 PDF资料
1.产 品 资 料 介 绍：
USHIO HB-50110AA OP1 电源模块，其产品特点可归纳如下：
属于USHIO超高压UV灯用光源电源装置。
适配USH-350D/USH-500D等UV汞灯，功率支持350W/500W切换。
采用单相100-120V交流输入。
小型轻量化开关电路设计，稳定性高、纹波低。
直流启动方式，减少对周边设备的噪声干扰。
输出稳定度±1%，电流纹波≤2.5%，保证照度均匀。
OP1与同系列OP2主要区别在于功率配置不同（OP2为640W）。
标准尺寸160×240×350mm，重约8kg，便于集成。
内置时间控制式快门，支持曝光时间精确管理。
可选配光量积分控制单元，实现曝光量精确控制。
具备过压、过流等基本保护功能。
典型应用于半导体光刻、LCD制造等精密曝光领域。
属工业专用设备，装配于USHIO各类光源单元中。
可搭配光纤、积分器、光导管等附件使用。
OP1为早期配置版本，选型时需确认功率需求与OP2的差异。
综上所述，USHIO HB-50110AA OP1 是一款稳定、低噪声的UV光源电源模块，适用于精密曝光和光固化应用。选型替换时注意350W/500W与OP2（640W）的功率区别。
USHIO HB-50110AA OP1 电源模块 英文介绍
The product features of USHIO HB-50110AA OP1 power module can be summarized as follows:
Belonging to the USHIO ultra-high voltage UV lamp light source power supply device.
Suitable for UV mercury lamps such as USH-350D/USH-500D, with power support for 350W/500W switching.
Adopting single-phase 100-120V AC input.
Small and lightweight switch circuit design with high stability and low ripple.
DC startup mode reduces noise interference to surrounding equipment.
Output stability ± 1%, current ripple ≤ 2.5%, ensuring uniform illumination.
The main difference between OP1 and the same series OP2 is the power configuration (OP2 is 640W).
The standard size is 160 × 240 × 350mm, weighing approximately 8kg, making it easy to integrate.
Built in time controlled shutter, supporting precise management of exposure time.
Optional light distribution integration control unit to achieve precise exposure control.
It has basic protection functions such as overvoltage and overcurrent.
Typical applications in precision exposure fields such as semiconductor lithography and LCD manufacturing.
It belongs to industrial specialized equipment and is assembled in various USHIO light source units.
Can be used with accessories such as optical fibers, integrators, and optical tubes.
OP1 is an early configuration version, and when selecting, it is necessary to confirm the difference in power requirements compared to OP2.
In summary, USHIO HB-50110AA OP1 is a stable and low-noise UV light source power module suitable for precision exposure and photopolymerization applications. Pay attention to the power difference between 350W/500W and OP2 (640W) when selecting and replacing.
USHIO HB-50110AA OP1 电源模块 产品图片
