SIEMENS 6SE6420-2AB17-5AA1 控制系统 PDF资料
1.产 品 资 料 介 绍：
SIEMENS 6SE6420-2AB17-5AA1 控制系统，其产品特点可归纳如下：
属于西门子MICROMASTER 420系列，是一款通用型变频器。
采用单相200-240V交流电源供电，设计紧凑。
额定输出功率为0.75kW，适用于中低功率驱动场景。
三相输出，额定输出电流3.9A，可驱动三相交流电机。
支持V/f线性、平方及可编程多点控制，满足不同负载特性需求。
采用磁通电流控制（FCC），可改善电机的动态响应特性。
具备快速电流限制（FCL）功能，可防止运行中不应有的跳闸。
集成RS485通讯接口，可扩展通讯能力。
配备3个数字量输入、1个模拟量输入、1个模拟量输出及1个继电器输出。
内置Class A级EMC滤波器，可有效抑制电磁干扰。
具备完善的保护功能，包括过压、欠压、过载、短路及电机过热保护等。
过载能力为150%额定电流，可持续60秒，提供良好的过载裕度。
采用模块化结构设计，组态灵活，便于维护与扩展。
防护等级为IP20，适合安装在控制柜内使用。
该型号内置滤波器且属于早期产品，选型或替换时需注意电源规格与操作面板的兼容性。
综上所述，SIEMENS 6SE6420-2AB17-5AA1 是一款功能全面、保护完善且控制灵活的MicroMaster 420系列变频器，适用于传送带、泵、风机及通用机械等工业自动化应用场景。
SIEMENS 6SE6420-2AB17-5AA1 控制系统 英文介绍
The product features of SIEMENS 6SE6420-2AB17-5AA1 control system can be summarized as follows:
Belonging to the Siemens MICROMASTER 420 series, it is a universal frequency converter.
Powered by a single-phase 200-240V AC power supply, the design is compact.
The rated output power is 0.75kW, suitable for low to medium power driving scenarios.
Three phase output, rated output current 3.9A, capable of driving three-phase AC motors.
Support V/f linear, square, and programmable multi-point control to meet different load characteristic requirements.
The use of flux current control (FCC) can improve the dynamic response characteristics of the motor.
Equipped with fast current limiting (FCL) function, it can prevent unnecessary tripping during operation.
Integrated RS485 communication interface, expandable communication capability.
Equipped with 3 digital inputs, 1 analog input, 1 analog output, and 1 relay output.
Built in Class A EMC filter can effectively suppress electromagnetic interference.
Equipped with comprehensive protection functions, including overvoltage, undervoltage, overload, short circuit, and motor overheating protection.
The overload capacity is 150% of the rated current and can last for 60 seconds, providing good overload margin.
Adopting a modular structure design, flexible configuration, and easy maintenance and expansion.
The protection level is IP20, suitable for installation in control cabinets.
This model has a built-in filter and is an early product. When selecting or replacing, attention should be paid to the compatibility between the power specifications and the operation panel.
In summary, SIEMENS 6SE6420-2AB17-5AA1 is a comprehensive, well protected, and flexibly controlled MicroMaster 420 series frequency converter suitable for industrial automation applications such as conveyor belts, pumps, fans, and general machinery.
SIEMENS 6SE6420-2AB17-5AA1 控制系统 产品图片
