Panasonic MSMA302P2D 伺服电机 PDF资料
1.产 品 资 料 介 绍：
Panasonic MSMA302P2D 伺服电机，其产品特点可归纳如下：
属于松下MINAS A4系列，为该家族的低惯量型伺服电机。
额定输出功率为3.0 kW，适用于中高功率驱动场景。
额定转速为3000 r/min，可满足多数自动化设备的高速运行需求。
额定转矩为9.54 N·m，能提供稳定的持续带载能力。
采用200V三相交流电源供电，适配标准的工业配电环境。
配备2500 P/r增量式编码器，可提供10000分辨率的精确位置反馈。
防护等级达到IP65，具备较好的防尘与防水能力，可适应一定恶劣环境。
绝缘等级为Class F，具有较高的耐热性能，保障电机长时间运行寿命。
电机轴型为圆形光轴，便于用户进行联轴器安装。
工作制为S1（连续工作制），适合需要长时间不间断运行的工况。
该电机为低惯量设计，能实现快速的加减速响应，适合频繁启停的应用。
电机与驱动器配合采用标准接口，信号传输稳定可靠。
机身法兰尺寸为130mm见方，安装孔距符合标准，方便替换或安装。
同系列电机产品线曾覆盖3.0kW规格，采用MSMA系列命名规则。
该型号属于早期产品，选型或替换时可参考A4系列同规格备选方案。
综上所述，Panasonic MSMA302P2D 是一款具备高功率密度、快速响应和良好防护特性的低惯量伺服电机，适用于对动态性能和可靠性有一定要求的工业自动化场合
Panasonic MSMA302P2D 伺服电机 英文介绍
The product features of Panasonic MSMA302P2D servo motor can be summarized as follows:
Belonging to the Panasonic MINAS A4 series, it is a low inertia servo motor of this family.
The rated output power is 3.0 kW, suitable for medium to high power driving scenarios.
The rated speed is 3000 r/min, which can meet the high-speed operation requirements of most automation equipment.
The rated torque is 9.54 N · m, which can provide stable continuous load capacity.
Powered by a 200V three-phase AC power supply, suitable for standard industrial distribution environments.
Equipped with a 2500 P/r incremental encoder, it can provide precise position feedback with a resolution of 10000.
The protection level reaches IP65, with good dust and water resistance, and can adapt to certain harsh environments.
The insulation level is Class F, with high heat resistance, ensuring the long-term operation life of the motor.
The motor shaft type is a circular optical axis, which is convenient for users to install the coupling.
The work system is S1 (continuous work system), suitable for working conditions that require long-term uninterrupted operation.
This motor is designed with low inertia and can achieve fast acceleration and deceleration response, making it suitable for applications with frequent start stop.
The motor and driver use standard interfaces for stable and reliable signal transmission.
The size of the body flange is 130mm square, and the installation hole spacing meets the standard, making it easy to replace or install.
The same series of motor product lines once covered a 3.0kW specification and adopted the MSMA series naming convention.
This model belongs to early products, and when selecting or replacing it, you can refer to the A4 series alternative solutions of the same specifications.
In summary, Panasonic MSMA302P2D is a low inertia servo motor with high power density, fast response, and good protection characteristics, suitable for industrial automation applications with certain requirements for dynamic performance and reliability
Panasonic MSMA302P2D 伺服电机 产品图片
