DALSA HS-80-08K80 扫描相机 PDF资料
1.产 品 资 料 介 绍：
DALSA HS-80-08K80 扫描相机 是一款基于TDI技术的高性能线阵工业相机，具备高速、高灵敏度和高分辨率的特点，适用于低光照和高速检测场景。
采用高灵敏度TDI CCD传感器。
分辨率8192像素，支持96级TDI。
最高行频68.6 kHz。
像元尺寸7μm x 7μm。
数据带宽最高640 MHz。
具备100倍抗光晕功能。
支持双向扫描。
可编程控制曝光、行频、触发等参数。
支持TDI模式或面阵模式切换。
内置平场校正功能。
支持像素合并。
Camera Link Full/Medium接口。
镜头接口M72x0.75。
工作温度0-50°C。
尺寸150×80×65mm，重约800g。
综上所述，DALSA HS-80-08K80 扫描相机以成熟的TDI技术和扎实的性能，成为高速工业检测领域的可靠选择
The DALSA HS-80-08K80 scanning camera is a high-performance linear array industrial camera based on TDI technology, featuring high speed, high sensitivity, and high resolution, suitable for low light and high-speed detection scenarios.
Adopting a high-sensitivity TDI CCD sensor.
Resolution 8192 pixels, supporting 96 level TDI.
The highest line frequency is 68.6 kHz.
Pixel size 7 μ m x 7 μ m.
The maximum data bandwidth is 640 MHz.
It has a 100x anti halo function.
Supports bidirectional scanning.
Programmable control of exposure, line frequency, trigger and other parameters.
Support switching between TDI mode or array mode.
Built in flat field correction function.
Support pixel merging.
Camera Link Full/Medium interface.
Lens interface M72x0.75.
The working temperature is 0-50 ° C.
Size 150 × 80 × 65mm, weight approximately 800g.
In summary, the DALSA HS-80-08K80 scanning camera, with its mature TDI technology and solid performance, has become a reliable choice in the field of high-speed industrial inspection
