IS200TREAS1A 终端板 PDF资料
1.产 品 资 料 介 绍：
IS200TREAS1A 终端板产品特点
开头：IS200TREAS1A 是通用电气为Mark VIe控制系统设计的航改型燃气轮机紧急停机终端板，与I/O包配合使用，实现关键安全保护功能，核心特点如下：
中间特点：
专为GE Mark VIe系列燃气轮机控制系统配套设计。
可与PPRO或YPRO涡轮I/O包配合使用。
支持三重冗余配置，提高系统安全性。
提供两种接线选项：24点插拔式端子块或48点欧式盒式端子。
配备9个被动脉冲测速装置，用于测量涡轮转速。
支持24V DC或125V DC的跳闸表决输出触点。
配备4路电压检测电路，持续监测跳闸回路状态。
提供子板连接器，支持功能扩展。
转速输入灵敏度为27mV，脉冲频率范围2Hz。
工作温度范围-30°C至+65°C，适应严苛环境。
支持危险场所认证，适用于爆炸性气体区域。
采用表面贴装技术，尺寸为33.0cm×17.8cm。
通道隔离耐压达1500VAC连续。
配合专用软件进行实时诊断与参数配置。
具备HART协议支持，实现与智能现场设备的通信。
结尾：综上，IS200TREAS1A 凭借三重冗余设计、灵活的转速监测和跳闸输出配置，是航改型燃气轮机紧急停机保护的关键硬件。
IS200WREAS1A 终端板 英文介绍
IS200TREAS1A Terminal Board Product Features
Introduction: IS200TREAS1A is an aviation modified gas turbine emergency stop terminal board designed by General Electric for the Mark VIe control system. It is used in conjunction with the I/O package to achieve critical safety protection functions. Its core features are as follows:
Intermediate characteristics:
Specially designed to complement the GE Mark VIe series gas turbine control system.
Can be used in conjunction with PPRO or YPRO turbine I/O packs.
Support triple redundancy configuration to improve system security.
Provide two wiring options: 24 point plug-in terminal block or 48 point European style box terminal.
Equipped with 9 arterial pulse velocity measurement devices for measuring turbine speed.
Support trip voting output contacts for 24V DC or 125V DC.
Equipped with 4 voltage detection circuits to continuously monitor the status of the trip circuit.
Provide daughter board connectors that support functional expansion.
The sensitivity of the speed input is 27mV, and the pulse frequency range is 2Hz.
The working temperature range is -30 ° C to+65 ° C, suitable for harsh environments.
Support hazardous location certification, suitable for explosive gas areas.
Using surface mount technology, the size is 33.0cm × 17.8cm.
The channel isolation withstand voltage reaches 1500VAC continuously.
Collaborate with specialized software for real-time diagnosis and parameter configuration.
Equipped with HART protocol support, enabling communication with intelligent field devices.
Conclusion: In summary, IS200TREAS1A, with its triple redundancy design, flexible speed monitoring, and trip output configuration, is a key hardware for emergency shutdown protection of aviation modified gas turbines.
IS200WREAS1A 终端板 产品图片
