IS200WREAS1A 终端板 PDF资料
1.产 品 资 料 介 绍：
IS200WREAS1A 终端板产品特点
开头：IS200WREAS1A 是通用电气为Mark VIe控制系统设计的紧急停机终端板，用于燃气轮机安全保护，核心特点如下：
中间特点：
专为GE Mark VIe燃气轮机控制系统配套设计。
作为紧急停机终端板的子板，与PPRA I/O包配合使用。
支持三重冗余配置，提高系统安全性。
提供润湿电压分配功能，为现场干接点供电。
配备4路隔离跳闸回路输入通道。
高阻抗电压检测，抗电气噪声能力强。
通道隔离耐压达1500VDC。
采用标准子板尺寸，直接插装于机箱背板。
工作温度范围-30°C至+65°C，适应严苛环境。
获得多项工业安全标准认证。
针对航改型燃机高速机械超速保护优化。
跳闸信号可直接路由至处理器执行保护逻辑。
具备危险场所认证，适用于爆炸性气体区域。
模块化设计，便于现场维护与更换。
适用于发电机组机舱等恶劣工业环境。
结尾：综上，IS200WREAS1A 具备可靠的安全保护功能和高隔离度，是Mark VIe系统紧急停机保护的关键硬件。
IS200WREAS1A 终端板 英文介绍
IS200WREAS1A Terminal Board Product Features
Introduction: IS200WREAS1A is an emergency stop terminal board designed by General Electric for Mark VIe control systems, used for gas turbine safety protection. Its core features are as follows:
Intermediate characteristics:
Specially designed to complement the GE Mark VIe gas turbine control system.
As a sub board for emergency stop terminal board, it is used in conjunction with PPRA I/O pack.
Support triple redundancy configuration to improve system security.
Provide wetting voltage distribution function to supply power to on-site dry contacts.
Equipped with 4 isolation trip circuit input channels.
High impedance voltage detection with strong resistance to electrical noise.
The channel isolation withstand voltage reaches 1500VDC.
Adopting standard motherboard size, directly plugged into the chassis backplane.
The working temperature range is -30 ° C to+65 ° C, suitable for harsh environments.
Obtained multiple industrial safety standard certifications.
Optimization of high-speed mechanical overspeed protection for aviation modified gas turbines.
The trip signal can be directly routed to the processor to execute protection logic.
Certified for hazardous locations and suitable for explosive gas areas.
Modular design facilitates on-site maintenance and replacement.
Suitable for harsh industrial environments such as generator compartments.
Conclusion: In summary, IS200WREAS1A has reliable safety protection functions and high isolation, making it a key hardware for emergency shutdown protection in the Mark VIe system.
IS200WREAS1A 终端板 产品图片
