NI PCI-1424 图像采集板 PDF资料
1.产 品 资 料 介 绍：
NI PCI-1424 图像采集板产品特点
开头：NI PCI-1424 是一款基于 PCI 总线的数字图像采集板卡，专为高速成像设计，其核心特点如下：
中间特点：
最高支持 50 MHz 像素时钟，采集速率达 200 MB/s。
支持 8 至 32 位并行数据，兼容灰度与彩色图像。
提供两种接口版本，适配 RS422/TTL 或 LVDS/TTL 相机。
板载 16 MB 帧缓存，可扩展至更大容量。
同时支持面阵与线阵数字相机。
配备 4 路可编程触发 I/O，便于外部控制。
内置 DMA 控制器，有效减轻 CPU 负载。
集成 RTSI 总线，可与其他板卡同步工作。
板载 NVRAM，上电自动加载配置。
提供 RS-232 串口，用于控制带串口的相机。
支持可编程数据格式与时钟生成。
随附 NI-IMAQ 驱动，兼容 LabVIEW 等开发环境。
可选配专用线缆，灵活扩展系统。
工作温度 0°C 至 55°C，适应工业环境。
符合多项国际安全与 EMC 标准。
结尾：总之，NI PCI-1424 采集速度快、兼容性强、软件支持完善，是工业视觉与科研成像的可靠选择。
NI PCI-1424 图像采集板 英文介绍
NI PCI-1424 Image Acquisition Board Product Features
Introduction: NI PCI-1424 is a digital image acquisition board based on PCI bus, designed for high-speed imaging. Its core features are as follows:
Intermediate characteristics:
Supports up to 50 MHz pixel clock and an acquisition rate of 200 MB/s.
Supports 8 to 32-bit parallel data, compatible with grayscale and color images.
Provide two interface versions, compatible with RS422/TTL or LVDS/TTL cameras.
Onboard 16 MB frame cache, expandable to larger capacities.
Simultaneously supporting both planar and linear digital cameras.
Equipped with 4 programmable trigger I/O channels for easy external control.
Built in DMA controller effectively reduces CPU load.
Integrated RTSI bus, can work synchronously with other boards.
Onboard NVRAM, automatically loads configuration upon power up.
Provide RS-232 serial port for controlling cameras with serial ports.
Supports programmable data formats and clock generation.
Comes with NI-IMAQ driver, compatible with development environments such as LabVIEW.
Optional dedicated cables for flexible system expansion.
The working temperature ranges from 0 ° C to 55 ° C, suitable for industrial environments.
Compliant with multiple international safety and EMC standards.
Conclusion: In summary, NI PCI-1424 has fast acquisition speed, strong compatibility, and complete software support, making it a reliable choice for industrial vision and scientific imaging.
NI PCI-1424 图像采集板 产品图片
