LION CPL290 电容式传感器 0190-C7681 PDF资料
1.产 品 资 料 介 绍：
LION CPL290 电容式传感器 0190-C7681 产品特点
LION CPL290 电容式传感器出自Lion Precision品牌，是一款采用电容技术的非接触式位移测量仪器，以亚纳米级分辨率和优异带宽性能著称，常用于精密定位与主轴回转误差分析等场景。以下为该型号的十五项主要特点：
Lion Precision原厂出品，电容传感领域技术积淀深厚。
非接触式测量，不损伤被测表面。
测量范围覆盖10 µm至12.5 mm，适配多种探头。
分辨率可达亚纳米级，精度极高。
线性度典型值±0.2%满量程。
标准带宽15 kHz，满足高转速测量需求。
支持用户可选带宽调节，灵活适配不同场景。
具备双量程切换功能，灵敏度可调。
输出±10 V模拟电压，接口通用。
前面板配备距离指示器，调零方便。
工作温度4°C至50°C，热稳定性良好。
支持单通道或多通道机箱配置。
可直接连接数据采集系统，集成便捷。
可选真空兼容探头，适应特殊环境。
符合主轴测量国际标准，适用于机床精度分析。
总而言之，CPL290电容式传感器精度高、带宽宽、适配灵活，是精密位移测量的可靠工具。具体探头匹配与校准参数请以附带证书为准。
LION CPL290 电容式传感器 0190-C7681 英文介绍
LION CPL290 Capacitive Sensor 0190-C7681 Product Features
LION CPL290 capacitive sensor is a non-contact displacement measurement instrument from Lion Precision brand, which adopts capacitive technology. It is known for its sub nanometer resolution and excellent bandwidth performance, and is commonly used in precision positioning and spindle rotation error analysis scenarios. The following are the fifteen main features of this model:
Produced by Lion Precision, with a deep technical foundation in the field of capacitive sensing.
Non contact measurement that does not damage the surface being measured.
The measurement range covers 10 µ m to 12.5 mm and is compatible with multiple probes.
The resolution can reach sub nanometer level and the accuracy is extremely high.
Typical linearity value ± 0.2% full scale.
The standard bandwidth is 15 kHz, which meets the requirements of high-speed measurement.
Support users to choose bandwidth adjustment and flexibly adapt to different scenarios.
Equipped with dual range switching function and adjustable sensitivity.
Output ± 10 V analog voltage, universal interface.
The front panel is equipped with a distance indicator for easy zeroing.
The working temperature is between 4 ° C and 50 ° C, and the thermal stability is good.
Supports single channel or multi-channel chassis configuration.
It can be directly connected to the data collection system, making integration convenient.
Optional vacuum compatible probe, suitable for special environments.
Complies with international standards for spindle measurement and is suitable for precision analysis of machine tools.
In summary, the CPL290 capacitive sensor has high accuracy, wide bandwidth, and flexible adaptability, making it a reliable tool for precise displacement measurement. Please refer to the attached certificate for specific probe matching and calibration parameters.
LION CPL290 电容式传感器 0190-C7681 产品图片
