TEL 3D81-000102-V1 接口模块 PDF资料
1.产 品 资 料 介 绍：
TEL 3D81-000102-V1 接口模块（TYB61C-1/TOP1）
- TEL 原厂专用接口 PCB，同型号可直接替换上机
- 衔接主控、伺服、传感器、气控单元传输混合信号
- 多路数字 + 模拟通道，采集温压、限位、真空反馈信号
- 内置光电隔离，强弱电分离，隔绝机柜电磁干扰
- 集成过流、过压、静电多重硬件防护
- 多组标准插槽端子，对接各类子控制板卡
- 沉金线路基板，耐洁净车间微量腐蚀气体
- 全板防潮阻焊涂层，防止凝露短路故障
- 加固贴片焊接，产线长期震动不易脱焊断线
- 板载状态指示灯，通讯、电源故障快速识别
- 支持设备内部总线，同步各腔体工艺指令
- 预留测试测点，现场校验、故障排查便捷
- 长条机架一体化布局，适配设备控制柜安装位
- 工业宽温元器件，冷热交替工况稳定运行
- 适配 7×24 小时不间断晶圆量产制程
TEL 3D81-000102-V1 Interface Module (TYB61C-1/TOP1)
Suitable for Tokyo Electronic Etching CVD、 Coating and developing semiconductor equipment, whole machine signal relay connection board
TEL factory specific interface PCB, the same model can be directly replaced on the machine
Connect the main control, servo, sensor, and pneumatic control units to transmit mixed signals
Multiple digital and analog channels, collecting temperature and pressure, limit, and vacuum feedback signals
Built in photoelectric isolation, strong and weak electrical separation, isolating cabinet electromagnetic interference
Integrated hardware protection against overcurrent, overvoltage, and static electricity
Multiple sets of standard slot terminals, compatible with various sub control boards
Gold plated circuit board, resistant to trace corrosive gases in clean workshops
Full board moisture-proof solder mask coating to prevent condensation and short circuit faults
Reinforced patch welding, long-term vibration of the production line is not easy to detach and break wires
Onboard status indicator light, quick identification of communication and power failures
Support internal bus of the device, synchronize process instructions of each cavity
Reserved testing points for convenient on-site verification and troubleshooting
Integrated layout of long rack, suitable for installation position of equipment control cabinet
Industrial wide temperature element device, stable operation under alternating cold and hot working conditions
Adapt to 7 × 24-hour uninterrupted wafer production process
Summary: TEL 3D81-000102-V1 is a signal exchange transfer board for semiconductor equipment, responsible for data exchange between the main control and various execution units, with strong anti-interference and convenient maintenance and replacement.
