1.产 品 资 料 介 绍：
GE Fanuc IC697PWR711 电源供应模块简介
IC697PWR711 是 GE Fanuc 90-70 系列 PLC 使用的机架电源模块，主要为 PLC 机架内的 CPU 和各类 I/O 模块提供稳定直流电源。它属于工业控制系统专用电源，并非普通外置电源适配器。
一、电气参数
输入电压范围：
交流输入：90–264VAC
直流输入：100–150VDC
输入频率：47–63Hz（交流）
输出功率：约 100W
输出电压规格：
+5VDC
+12VDC
-12VDC
具备过压、过流、短路保护功能
二、结构与安装
模块化设计，安装在 90-70 系列机架最左侧电源槽位
通过背板为整个机架供电
支持单机架系统应用
工业级设计，适用于严苛工业环境
三、应用特点
输出稳定性高，满足 PLC 系统连续运行需求
抗干扰能力强
具备电源掉电保持能力
适用于发电、电力、石化、制造等工业自动化系统
四、注意事项
该型号为机架内部电源模块，不能作为普通外接电源适配器使用
更换时需确认系统电压等级及负载容量
安装前必须断电操作
IC697PWR711电源供应适配器 英文介绍
Introduction to GE Fanuc IC697PWR711 Power Supply Module
IC697PWR711 is a rack power module used in GE Fanuc 90-70 series PLCs, mainly providing stable DC power for CPUs and various I/O modules inside the PLC rack. It belongs to the specialized power supply for industrial control systems and is not a regular external power adapter.
1、 Electrical parameters
Input voltage range:
Communication input: 90-264VAC
DC input: 100-150VDC
Input frequency: 47-63Hz (AC)
Output power: approximately 100W
Output voltage specification:
+5VDC
+12VDC
-12VDC
Equipped with overvoltage, overcurrent, and short-circuit protection functions
2、 Structure and Installation
Modular design, installed in the leftmost power slot of the 90-70 series rack
Power the entire rack through the backplane
Support single rack system applications
Industrial grade design, suitable for harsh industrial environments
3、 Application features
High output stability, meeting the continuous operation requirements of PLC systems
Strong anti-interference ability
Capable of maintaining power supply in case of power failure
Suitable for industrial automation systems such as power generation, electricity, petrochemicals, manufacturing, etc
4、 Precautions
This model is an internal power module for the rack and cannot be used as a regular external power adapter
When replacing, it is necessary to confirm the system voltage level and load capacity
Power off operation is required before installation
