1.产 品 资 料 介 绍：
IC697MEM713 存储模块
IC697MEM713 是 GE Fanuc 90-70 系列 PLC 的一个存储扩展模块，用于为控制系统提供程序和数据存储空间。它作为 CPU 的辅助存储单元，可以保存程序、变量和系统配置等关键信息。
主要功能与作用
扩展存储空间：增加 PLC 系统的程序和数据容量，适用于大程序规模或复杂系统。
掉电存储：采用非易失性存储设计，断电后数据不丢失，确保程序和关键数据长期保存。
兼容性好：可与 90-70 系列的 CPU 兼容，用于替代或扩展原有存储配置。
快速访问：存储模块数据可由 CPU 快速访问，提高系统执行效率。
易于维护：模块化设计可插拔更换，便于现场维护与升级。
技术特点
高可靠性：工业级设计，稳定性强，适合连续运行环境。
大容量存储：比基本 CPU 自带的存储更大，支持复杂程序结构。
断电保护：内置电池或其他保持电路，在断电时保留数据。
与 PLC 系统无缝集成：支持与 CPU 模块高速数据交互，无需额外配置。
轻松更换与安装：插卡式结构，现场更换简单，减少停机时间。
支持故障诊断：能与系统诊断功能配合，辅助识别存储异常。
应用场景
大型自动化生产线：需要更多程序段和数据存储的场合。
程序迭代频繁：开发调试环境下需要存储多版本程序。
数据日志保存：用于保存生产数据、状态记录等。
应急备份存储：作为 CPU 内存不足时的扩展和备份单元。
IC697MEM713存储模块 英文介绍
IC697MEM713 storage module
IC697MEM713 is a storage expansion module for GE Fanuc 90-70 series PLCs, used to provide program and data storage space for control systems. As an auxiliary storage unit of the CPU, it can store key information such as programs, variables, and system configurations.
Main functions and functions
Expand storage space: Increase the program and data capacity of PLC systems, suitable for large-scale or complex systems.
Power down storage: adopting non-volatile storage design, data will not be lost after power failure, ensuring long-term preservation of programs and critical data.
Good compatibility: Compatible with 90-70 series CPUs, used to replace or expand existing storage configurations.
Quick Access: Storage module data can be quickly accessed by the CPU, improving system execution efficiency.
Easy to maintain: The modular design is pluggable and replaceable, making it convenient for on-site maintenance and upgrades.
Technical Features
High reliability: Industrial grade design, strong stability, suitable for continuous operation environment.
Large capacity storage: larger than the built-in storage of a basic CPU, supporting complex program structures.
Power outage protection: Built in battery or other holding circuit to retain data in case of power outage.
Seamless integration with PLC system: supports high-speed data exchange with CPU modules without additional configuration.
Easy replacement and installation: The plug-in card structure makes on-site replacement simple and reduces downtime.
Support fault diagnosis: Can cooperate with system diagnostic functions to assist in identifying storage anomalies.
Application scenarios
Large scale automated production lines: occasions that require more program segments and data storage.
Frequent program iterations: Multiple versions of the program need to be stored in the development and debugging environment.
Data log storage: used to store production data, status records, etc.
Emergency backup storage: serves as an expansion and backup unit when the CPU memory is insufficient.
