Varian 8698933R001涡轮光谱仪 PDF资料
Varian 8698933R001是一款涡轮分子泵，属于Varian（现属Agilent）TV 902 Navigator系列，抽速680 L/s，极限压力可达1 x 10⁻¹⁰ mbar，意大利制造，广泛用于质谱分析等分析仪器。
5条产品特点
属于TV 902 Navigator系列涡轮分子泵，采用DN 160 ISO-F高真空法兰接口
配备高频电机驱动涡轮，采用8级叶片和4级MacroTorr拖动级设计
涡轮转子由永久润滑高精度陶瓷球轴承支撑，安装在真空侧
配备专用Navigator控制器（SQ 337），支持RS232/RS485远程通讯
结构紧凑，适合集成到各类分析仪器和工业设备中
5条产品参数
型号：8698933R001
产品系列：TV 902 Navigator
抽速（N2）：680 L/s
极限压力：1 x 10⁻¹⁰ mbar
进气口法兰：DN 160 ISO-F
产地：意大利
5个应用领域
质谱分析仪器（LC-MS/MS、ICP-MS）
电子显微镜真空系统
半导体制造设备
表面分析仪器
科研高真空系统
总的来说，Varian 8698933R001是TV 902 Navigator系列的涡轮分子泵，抽速680 L/s，极限压力达1 x 10⁻¹⁰ mbar，在质谱分析、电子显微和半导体制造等对真空要求苛刻的领域应用广泛，是Varian涡轮泵产品线中的经典型号。
Varian 869893R001 is a turbomolecular pump belonging to the Varian (now Agilent) TV 902 Navigator series, with a pumping speed of 680 L/s and a maximum pressure of 1 x 10 ⁻¹⁰ mbar. It is manufactured in Italy and widely used in analytical instruments such as mass spectrometry.
5 Product Features
Belonging to the TV 902 Navigator series turbo molecular pump, it adopts DN 160 ISO-F high vacuum flange interface
Equipped with a high-frequency motor to drive the turbine, adopting an 8-stage blade and 4-stage MacroTorr drag stage design
The turbine rotor is supported by permanently lubricated high-precision ceramic ball bearings and installed on the vacuum side
Equipped with a dedicated Navigator controller (SQ 337), supporting RS232/RS485 remote communication
Compact structure, suitable for integration into various analytical instruments and industrial equipment
5 product parameters
Model: 8698933R001
Product Series: TV 902 Navigator
Extraction speed (N2): 680 L/s
Ultimate pressure: 1 x 10 ⁻¹⁰ mbar
Inlet flange: DN 160 ISO-F
Origin: Italy
5 application areas
Mass spectrometry analysis instruments (LC-MS/MS, ICP-MS)
Electron microscope vacuum system
Semiconductor manufacturing equipment
Surface analysis instrument
Research High Vacuum System
Overall, Varian 869893R001 is a turbo molecular pump from the TV 902 Navigator series, with a pumping speed of 680 L/s and a maximum pressure of 1 x 10 ⁻¹⁰ mbar. It is widely used in fields such as mass spectrometry analysis, electron microscopy, and semiconductor manufacturing that require strict vacuum requirements, and is a classic model in Varian's turbo pump product line.
