Leybold 410400V0505涡轮泵 PDF资料
Leybold 410400V0505是莱宝（Leybold）TURBOVAC MAG W 400 iP系列涡轮分子泵，采用磁悬浮轴承设计，抽速365 L/s，德国制造，是一款用于高真空环境的涡轮泵。
5条产品特点
采用磁悬浮轴承技术，转子无接触运行，无需润滑，维护成本低
集成变频器和电源，无需传统机架式控制器和连接电缆
支持任意方向安装，采用对流冷却方式
配备DN 160 ISO-K高真空法兰和DN 16 ISO-KF前级法兰
对轻气体具有高压缩比，启动时间小于5分钟
5条产品参数
型号：410400V0505
产品系列：TURBOVAC MAG W 400 iP
抽速（N2）：365 L/s
极限压力：< 1 x 10⁻¹⁰ mbar
最高转速：58,800 rpm
产地：德国
5个应用领域
半导体制造设备
质谱分析仪器
电子显微镜真空系统
表面分析设备
科研高真空系统
总的来说，Leybold 410400V0505是TURBOVAC MAG W 400 iP系列磁悬浮涡轮分子泵，采用无接触磁悬浮轴承和集成驱动设计，在半导体制造、质谱分析和科研高真空领域应用广泛，是莱宝涡轮泵产品线中的经典型号
Leybold 410400V0505 is a Leybold TURBOVAC MAG W 400 iP series turbomolecular pump designed with magnetic levitation bearings and a pumping speed of 365 L/s. It is manufactured in Germany and is designed for high vacuum environments.
5 Product Features
Adopting magnetic levitation bearing technology, the rotor operates without contact, requires no lubrication, and has low maintenance costs
Integrated frequency converter and power supply, eliminating the need for traditional rack mounted controllers and connecting cables
Support installation in any direction, using convection cooling method
Equipped with DN 160 ISO-K high vacuum flange and DN 16 ISO-KF front flange
High compression ratio for light gases, with a start-up time of less than 5 minutes
5 product parameters
Model: 410400V0505
Product Series: TURBOVAC MAG W 400 iP
Extraction speed (N2): 365 L/s
Ultimate pressure:<1 x 10 ⁻¹⁰ mbar
Maximum speed: 58800 rpm
Origin: Germany
5 application areas
Semiconductor manufacturing equipment
Mass spectrometry analyzer
Electron microscope vacuum system
Surface analysis equipment
Research High Vacuum System
In general, Leybold 410400V0505 is a TURBOVAC MAG W 400 iP series magnetic levitation turbo molecular pump, which adopts non-contact magnetic levitation bearings and integrated drive design. It is widely used in semiconductor manufacturing, mass spectrometry analysis, and research high vacuum fields, and is a classic model in the Leybold turbo pump product line
