ADVANTECH SOM-4450 工业控制主板 PDF资料
1.产 品 资 料 介 绍：
ADVANTECH SOM-4450 工业控制主板
ADVANTECH SOM-4450 工业控制主板的核心特点如下：
采用AMD Geode GX1-300 MHz低功耗处理器，支持无风扇运行。
板载AMD CS5530A芯片组，集成VGA/LCD显示控制器。
配备1个SODIMM内存插槽，最大支持256MB SDRAM。
支持CRT和18-bit TTL LCD双显示输出。
SOM-4450FL子型号支持单通道LVDS接口，传输距离可达10米。
集成RealTek RTL 8139 10/100Mbps以太网控制器。
支持AC'97音频，提供Line-in、Line-out、Mic-in接口。
板载CH7003 TV-out芯片，支持NTSC/PAL及S-Video输出。
提供1个板载CompactFlash插槽，用于固态存储。
配备2个USB 1.1接口、2个RS-232串口、1个并口及PS/2接口。
支持2个EIDE通道，最多连接4个IDE设备。
内置62级看门狗定时器，支持系统复位。
采用ETX标准尺寸（95×114mm），通过高密度连接器与载板对接。
ADVANTECH SOM-4450 工作温度范围0~60°C。
功耗低于8W（典型值1.5A@5V），适合低功耗嵌入式场景。
综上，ADVANTECH SOM-4450 是一款低功耗ETX架构系统核心板，适用于工业控制、医疗设备、自助终端等领域。
ADVANTECH SOM-4450 工业控制主板 英文介绍
ADVANTECH SOM-4450 Industrial Control Motherboard
The core features of the ADVANTECH SOM-4450 industrial control motherboard are as follows:
Adopting AMD Geode GX1-300 MHz low-power processor, supporting fanless operation.
Onboard AMD CS5530A chipset, integrated with VGA/LCD display controller.
Equipped with one SODIMM memory slot, supporting up to 256MB SDRAM.
Supports dual display output of CRT and 18 bit TTL LCD.
The SOM-4450FL sub model supports a single channel LVDS interface, with a transmission distance of up to 10 meters.
Integrated RealTek RTL 8139 10/100Mbps Ethernet controller.
Supports AC'97 audio and provides Line in, Line out, and Mic in interfaces.
Onboard CH7003 TV out chip, supporting NTSC/PAL and S-Video output.
Provide one onboard CompactFlash slot for solid-state storage.
Equipped with 2 USB 1.1 interfaces, 2 RS-232 serial ports, 1 parallel port, and PS/2 interfaces.
Supports 2 EIDE channels and can connect up to 4 IDE devices.
Built in 62 level watchdog timer, supports system reset.
Using ETX standard size (95 × 114mm), it is connected to the carrier board through high-density connectors.
ADVANTECH SOM-4450 operates within a temperature range of 0-60 ° C.
Power consumption below 8W (typical value) 1.5A@5V ）Suitable for low-power embedded scenarios.
Overall, ADVANTECH SOM-4450 is a low-power ETX architecture system core board suitable for industrial control, medical equipment, self-service terminals, and other fields.
ADVANTECH SOM-4450 工业控制主板 产品图片
