LXM05AD17M2 伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
LXM05AD17M2 伺服驱动器产品特点
LXM05AD17M2 是施耐德电气 Lexium 05 系列的一款伺服驱动器，适配 200-240V 单相供电系统，用于驱动 BSH 系列伺服电机，具体特点如下。
属于 Lexium 05 系列伺服驱动器，输入电压 200-240V 单相。
额定功率 1.2kW，适用于中等功率工业场景。
配套 BSH 电机时，堵转扭矩 2.12 N·m。
峰值扭矩 4.14 N·m，满足短时过载需求。
配套 BSH 电机额定输出功率 600W。
支持 3000rpm 额定转速。
配套 BSH 电机额定扭矩 1.9 N·m。
支持 Modbus 总线通讯。
支持 CANopen 现场总线，集成灵活。
内置 Power Removal 安全功能，符合 SIL2 等级。
提供电流、速度、电子齿轮、位置等多种控制模式。
支持 ±10V 模拟量控制或脉冲/方向指令输入。
配套 BSH 电机编码器分辨率 131072 点/转，定位精度高。
包含过载、过压、过温等多项保护功能。
防护等级 IP20，适合控制柜内安装。
总之，LXM05AD17M2 是一款功能全面的伺服驱动器，集多种控制模式与总线支持于一体，适用于需要灵活配置和可靠性能的工业自动化场景
LXM05AD17M2 伺服驱动器 英文介绍
Product Features of LXM05AD17M2 Servo Drive
LXM05AD17M2 is a servo drive from Schneider Electric's Lexium 05 series, compatible with a 200-240V single-phase power supply system, used to drive BSH series servo motors. Its specific features are as follows.
Belonging to the Lexium 05 series servo drive, with an input voltage of 200-240V single-phase.
Rated power of 1.2kW, suitable for medium power industrial scenarios.
When paired with BSH motor, the locked rotor torque is 2.12 N · m.
The peak torque is 4.14 N · m, which meets the short-term overload demand.
The rated output power of the BSH motor is 600W.
Supports a rated speed of 3000rpm.
The rated torque of the BSH motor is 1.9 N · m.
Supports Modbus bus communication.
Supports CANopen fieldbus and flexible integration.
Built in Power Removal security function, compliant with SIL2 level.
Provide multiple control modes such as current, speed, electronic gear, position, etc.
Supports ± 10V analog control or pulse/direction command input.
The supporting BSH motor encoder has a resolution of 131072 points per revolution and high positioning accuracy.
It includes multiple protection functions such as overload, overvoltage, and overheating.
Protection level IP20, suitable for installation inside control cabinets.
In summary, LXM05AD17M2 is a comprehensive servo drive that integrates multiple control modes and bus support, suitable for industrial automation scenarios that require flexible configuration and reliable performance
LXM05AD17M2 伺服驱动器 产品图片
