HP DMC-2142-DC24 运动控制板 PDF资料
1.产 品 资 料 介 绍：
- 标准 DC24V 直流供电规格，适配设备内部供电回路
- 支持四轴独立同步控制，点位运动、圆弧插补均可实现
- 搭载 32 位处理芯片，运动运算响应快，轨迹运行顺滑
- 双通讯接口，以太网加 RS232 串口，上位机连接稳定
- 每轴配备双路编码器反馈，定位重复精度高无偏移
- 内置 PID 动态补偿算法，加减速平稳降低机械冲击
- 自带 8 路数字输入、8 路数字输出，联动外部感应元件
- 非易失存储芯片，断电保存运动程序与设备参数
- 支持电子齿轮、电子凸轮模式，适配印刷走纸工位
- 板载隔离电路，隔绝车间静电、电磁干扰防报错
- 100 针标准集成接口，接线规整，拆装替换便捷
- 内置多重硬件保护，过压、过流、短路自动切断
- 全板防潮阻焊涂层，适配工业车间长期连续作业
- 兼容伺服、步进两类驱动，设备改造适配性强
- 工业级贴片元器件，长时间运行发热低故障率小
This HP DMC-2142-DC24 motion control board is compatible with HP large format printing equipment and uses a 24V DC power supply four axis motion control motherboard
Standard DC24V DC power supply specification, compatible with internal power supply circuits of equipment
Support four axis independent synchronous control, both point motion and arc interpolation can be achieved
Equipped with a 32-bit processing chip, the motion calculation response is fast and the trajectory runs smoothly
Dual communication interface, Ethernet and RS232 serial port, stable connection to the upper computer
Each axis is equipped with dual encoder feedback, with high positioning repeatability and no offset
Built in PID dynamic compensation algorithm, smooth acceleration and deceleration to reduce mechanical impact
Comes with 8 digital inputs and 8 digital outputs, linked with external sensing components
Non volatile storage chip, power off to save motion programs and device parameters
Support electronic gear and electronic cam modes, suitable for printing and paper feeding stations
Onboard isolation circuit, isolating workshop static electricity and electromagnetic interference to prevent errors
100 pin standard integrated interface, neat wiring, easy disassembly and replacement
Built in multiple hardware protections, automatic cut-off for overvoltage, overcurrent, and short circuit
Full board moisture-proof solder mask coating, suitable for long-term continuous operation in industrial workshops
Compatible with both servo and stepper drivers, with strong adaptability for equipment modification
Industrial grade surface mount components with low heat generation and low failure rate during long-term operation
Summary: The HP DMC-2142-DC24 motion control board has stable four axis synchronization performance, reliable communication, and can directly replace the original control motherboard of printing equipment.
