BECKHOFF AM8042-0E10-00 伺服电机 PDF资料
1.产 品 资 料 介 绍：
BECKHOFF AM8042-0E10-00 伺服电机产品特点
BECKHOFF AM8042-0E10-00是德国倍福AM8000系列的一款三相永磁同步伺服电机，法兰尺寸F4（87mm），适用于100-480V AC电压范围的高动态驱动应用，具体特点如下。
采用三相永磁同步电机设计，转子惯量1.98 kgcm²。
额定电压范围100-480V AC，兼容单相和三相供电。
堵转扭矩4.10 Nm，提供可靠启动力矩。
峰值扭矩18.9 Nm，满足短时过载需求。
额定转速2500 min⁻¹，额定功率1.02kW。
额定扭矩3.90 Nm，连续运行稳定可靠。
采用对流冷却方式，无需复杂冷却管路。
轴径19 k6，伸出长度40mm。
可选配无背隙永磁保持制动器（9 Nm保持力矩）。
支持旋转变压器、OCT单圈/多圈绝对值编码器等多种反馈。
可选EnDat 3接口，支持SIL 2或SIL 3功能安全。
M23 speedtec连接器，安装维护便捷。
防护等级IP54（标配），IP65（带轴封）。
环境温度范围+5-+40°C，适应常规工业环境。
支持IM B5、IM V1、IM V3等多种法兰安装方式。
总之，BECKHOFF AM8042-0E10-00以4.10 Nm堵转扭矩和灵活的编码器配置，在紧凑尺寸内提供了高性能驱动方案，适用于对动态响应和定位精度要求较高的自动化设备。
BECKHOFF AM8042-0E10-00 伺服电机 英文介绍
BECKHOFF AM8042-0E10-00 Servo Motor Product Features
BECKHOFF AM8042-0E10-00 is a three-phase permanent magnet synchronous servo motor from the German Beckhoff AM8000 series, with a flange size of F4 (87mm), suitable for high dynamic drive applications in the 100-480V AC voltage range. The specific features are as follows.
Designed with a three-phase permanent magnet synchronous motor, the rotor inertia is 1.98 kgcm ².
Rated voltage range 100-480V AC, compatible with single-phase and three-phase power supply.
The locked torque is 4.10 Nm, providing reliable starting torque.
The peak torque is 18.9 Nm, meeting the short-term overload demand.
Rated speed 2500 min ⁻¹, rated power 1.02kW.
Rated torque of 3.90 Nm, stable and reliable continuous operation.
Adopting convective cooling method, there is no need for complex cooling pipelines.
The shaft diameter is 19 k6 and the extension length is 40mm.
Optional backless permanent magnet holding brake (9 Nm holding torque).
Support multiple feedbacks such as rotary transformers, OCT single/multi turn absolute encoders, etc.
Optional EnDat 3 interface, supporting SIL 2 or SIL 3 functional safety.
M23 Speedtec connector, easy to install and maintain.
Protection level IP54 (standard), IP65 (with shaft seal).
The ambient temperature range is+5-+40 ° C, suitable for conventional industrial environments.
Supports multiple flange installation methods such as IM B5, IM V1, IM V3, etc.
In summary, BECKHOFF AM8042-0E10-00 provides a high-performance drive solution in a compact size with a 4.10 Nm locked rotor torque and flexible encoder configuration, suitable for automation equipment that requires high dynamic response and positioning accuracy.
BECKHOFF AM8042-0E10-00 伺服电机 产品展示
