6SL3130-6TE23- 6AB0 电源模块 PDF资料
1.产 品 资 料 介 绍：
6SL3130-6TE23-6AB0 电源模块产品特点
6SL3130-6TE23-6AB0是西门子SINAMICS S120驱动系统的智能型电源模块，用于将三相交流电转换为稳定的直流电，为后续电机模块供电，具体特点如下。
属于SINAMICS S120系列智能型电源模块。
输入电压三相380-480V AC，50/60Hz。
输出直流600V DC，额定母线电流60A。
额定功率36kW。
采用内部风冷方式散热。
配备DRIVE-CLiQ数字通信接口。
包含控制电压适配器。
书本尺寸，宽150mm、高380mm、深270mm。
净重约10.3kg。
防护等级IP20，适合控制柜内安装。
不带能量回馈功能，制动需外接制动单元和电阻。
适用于风机、泵类等基础驱动场景。
可安装于单轴或多轴驱动系统。
工作环境温度0-40℃。
已停产，后继型号为6SL3130-6TE23-6AA3。
总之，6SL3130-6TE23-6AB0是SINAMICS S120系统的可靠直流供电方案，虽已停产，仍是设备维护和备件采购时需要关注的关键部件。
6SL3130-6TE23-6AB0 power module product features
6SL3130-6TE23-6AB0 is an intelligent power module for the Siemens SINAMICS S120 drive system, used to convert three-phase AC power into stable DC power to supply power to subsequent motor modules. Its specific features are as follows.
Belonging to the SINAMICS S120 series intelligent power module.
Input voltage: three-phase 380-480V AC, 50/60Hz.
Output DC 600V DC, rated bus current 60A.
The rated power is 36kW.
Adopt internal air cooling method for heat dissipation.
Equipped with DRIVE CLiQ digital communication interface.
Includes control voltage adapter.
The book size is 150mm wide, 380mm high, and 270mm deep.
The net weight is approximately 10.3kg.
Protection level IP20, suitable for installation inside control cabinets.
Without energy feedback function, external braking unit and resistor are required for braking.
Suitable for basic driving scenarios such as fans and pumps.
Can be installed on single axis or multi axis drive systems.
The working environment temperature is 0-40 ℃.
Discontinued, the successor model is 6SL3130-6TE23-6AA3.
In summary, 6SL3130-6TE23-6AB0 is a reliable DC power supply solution for the SINAMICS S120 system. Although it has been discontinued, it is still a key component that needs attention during equipment maintenance and spare parts procurement.
