ACS UDMpm2-320A007-QTM3 运动控制控制器 PDF资料
1.产 品 资 料 介 绍：
ACS UDMpm2-320A007-QTM3 运动控制控制器产品特点
ACS UDMpm2-320A007-QTM3 是一款面向高性能运动控制应用的通用驱动模块，兼容交流伺服、直流无刷、直流有刷等多种电机类型。
产品特点：
支持单轴或双轴驱动配置，灵活适配不同应用需求。
兼容交流伺服、直流无刷、直流有刷等多种电机。
基于EtherCAT总线通讯，集成于SPiiPlus控制平台。
输入电压范围85至265Vac，适应工业现场供电条件。
每轴连续电流7.5A，峰值电流15A，功率约1.6kW/3.2kW。
控制环采样与更新速率达20kHz，动态响应迅速。
每轴支持双反馈双回路控制，定位精度更高。
支持增量式、正余弦模拟量、绝对式编码器及分解器。
数字I/O配置为8输入8输出，模拟I/O为4输入2输出。
可选配安全转矩关断功能，符合SIL-3和PLe安全等级。
配备独立24Vdc控制电源，紧急情况下保持信号供电。
具备完善的过压、过流、短路等电气保护功能。
专为半导体、FPD、电子制造、激光加工等高端应用设计。
综合来看，ACS UDMpm2-320A007-QTM3 以灵活的驱动配置、精准的控制性能和可靠的安全保护，满足高端装备对高精度运动控制的严苛要求。
ACS UDMpm2-320A007-QTM3 运动控制控制器 英文介绍
ACS UDMpm2-320A007-QTM3 Motion Control Controller Product Features
ACS UDMpm2-320A007-QTM3 is a universal drive module designed for high-performance motion control applications, compatible with various motor types such as AC servo, DC brushless, and DC brushed.
Product Features:
Supports single axis or dual axis drive configurations, flexibly adapting to different application requirements.
Compatible with various motors such as AC servo, DC brushless, DC brushed, etc.
Based on EtherCAT bus communication, integrated into the SPiiPlus control platform.
The input voltage range is 85 to 265Vac, suitable for industrial power supply conditions.
Each axis has a continuous current of 7.5A, a peak current of 15A, and a power of approximately 1.6kW/3.2kW.
The sampling and updating rate of the control loop reaches 20kHz, with rapid dynamic response.
Each axis supports dual feedback and dual loop control, resulting in higher positioning accuracy.
Supports incremental, sine cosine analog, absolute encoders and decomposers.
The digital I/O configuration is 8 inputs and 8 outputs, while the analog I/O configuration is 4 inputs and 2 outputs.
Optional safety torque shutdown function, compliant with SIL-3 and PLe safety levels.
Equipped with an independent 24Vdc control power supply to maintain signal power supply in emergency situations.
It has complete electrical protection functions such as overvoltage, overcurrent, and short circuit.
Specially designed for semiconductors FPD、 Design high-end applications such as electronic manufacturing and laser processing.
Overall, the ACS UDMpm2-320A007-QTM3 meets the stringent requirements of high-end equipment for high-precision motion control with its flexible drive configuration, precise control performance, and reliable safety protection.
