Panasonic MHMA052P3C 交流伺服电机 PDF资料
1.产 品 资 料 介 绍：
Panasonic MHMA052P3C 交流伺服电机产品特点
Panasonic MHMA052P3C 是一款MINAS A4系列的交流伺服电机，属于高惯量类型，适用于对定位精度和响应速度要求较高的工业自动化场合。以下是该型号的15项核心特点：
额定功率500W，满足中等功率应用需求。
额定转速2000r/min，最高转速可达3000r/min。
额定扭矩2.38N·m，瞬时最大峰值扭矩6N·m。
配备17位增量式/绝对式编码器，定位精度高。
采用高惯量转子设计，运行平稳。
IP65防护等级，适合粉尘及潮湿环境使用。
标配油封结构，防止油脂渗入电机内部。
法兰尺寸130mm×130mm，安装紧凑。
采用连接器引出方式，接线快速可靠。
支持200VAC电压规格，适配标准工业电源。
内置自适应滤波器，可根据机械振动自动调整。
响应频率最高可达1kHz，动态响应快。
抗过载能力强，可承受3倍额定转矩。
工作温度范围0℃~40℃，适应一般工业环境。
符合CE、UL等国际安全认证标准。
总之，Panasonic MHMA052P3C伺服电机凭借高精度编码器、高惯量设计、良好防护性能及智能振动抑制功能，为工业自动化设备提供了稳定可靠的驱动解决方案。
Panasonic MHMA052P3C 交流伺服电机 英文介绍
Panasonic MHMA052P3C AC servo motor product features
Panasonic MHMA052P3C is a MINAS A4 series AC servo motor, belonging to the high inertia type, suitable for industrial automation applications that require high positioning accuracy and response speed. Here are the 15 core features of this model:
Rated power of 500W, meeting the requirements of medium power applications.
The rated speed is 2000r/min, and the maximum speed can reach 3000r/min.
The rated torque is 2.38N · m, and the instantaneous maximum peak torque is 6N · m.
Equipped with a 17 bit incremental/absolute encoder, it has high positioning accuracy.
Adopting a high inertia rotor design, it runs smoothly.
IP65 protection level, suitable for use in dusty and humid environments.
Standard oil seal structure to prevent grease from seeping into the interior of the motor.
The flange size is 130mm × 130mm, and the installation is compact.
Using connector lead out method, the wiring is fast and reliable.
Supports 200VAC voltage specifications and is compatible with standard industrial power supplies.
Built in adaptive filter that can automatically adjust according to mechanical vibration.
The response frequency can reach up to 1kHz, with fast dynamic response.
Strong overload resistance, capable of withstanding 3 times the rated torque.
The working temperature range is 0 ℃~40 ℃, suitable for general industrial environments.
Compliant with international safety certification standards such as CE and UL.
In summary, the Panasonic MHMA052P3C servo motor provides a stable and reliable driving solution for industrial automation equipment with its high-precision encoder, high inertia design, good protection performance, and intelligent vibration suppression function.
Panasonic MHMA052P3C 交流伺服电机 产品展示
