Agilis ALB12822C8-VO 控制器模块 PDF资料
1.产 品 资 料 介 绍：
Agilis ALB12822C8-VO 控制器模块是一款面向卫星通信领域的Ku波段室外上变频模块，集成了上变频、功率放大与电源管理功能，其核心特点如下。
中间15条：
Agilis ALB12822C8-VO 输出频率覆盖13.75至14.50GHz Ku波段。
中频输入范围为950至1700MHz。
本振频率为12.80GHz。
输出功率P1dB不低于39dBm，约合8W。
输入电压范围宽，支持18V至60V直流供电。
采用L波段中频接口与室内单元连接。
工作温度范围宽，可适应-40℃至+60℃环境。
具备IP65防水等级，适用于室外恶劣天气条件。
支持RS232/485标准监控接口。
支持网络监控功能，便于远程管理。
内置自动温度补偿功能，保证全温范围增益稳定。
线性度高，杂散抑制优异。
具备增益可调功能，支持射频输出静音控制。
Agilis ALB12822C8-VO 支持冗余配置，适用于高可靠性通信需求场景。
采用直接天线安装设计，结构紧凑。
结尾：
综上，Agilis ALB12822C8-VO 在射频输出性能、环境适应能力及远程监控功能方面均有良好表现，是卫星通信系统中较为可靠的上变频功率放大组件。
Agilis ALB12822C8-VO 控制器模块 英文介绍
The Agilis ALB12822C8-VO controller module is a Ku band outdoor up conversion module designed for the satellite communication field. It integrates up conversion, power amplification, and power management functions. Its core features are as follows.
Middle 15:
The output frequency of Agilis ALB12822C8-VO covers the 13.75 to 14.50GHz Ku band.
The intermediate frequency input range is 950 to 1700MHz.
The local oscillator frequency is 12.80GHz.
The output power P1dB is not less than 39dBm, which is approximately 8W.
Wide input voltage range, supporting 18V to 60V DC power supply.
Connect to indoor units using an L-band intermediate frequency interface.
The working temperature range is wide and can adapt to environments ranging from -40 ℃ to+60 ℃.
Equipped with IP65 waterproof rating, suitable for outdoor harsh weather conditions.
Supports RS232/485 standard monitoring interface.
Support network monitoring function for remote management.
Built in automatic temperature compensation function ensures stable gain across the entire temperature range.
High linearity and excellent spurious suppression.
Equipped with adjustable gain function and supporting RF output mute control.
Agilis ALB12822C8-VO supports redundant configuration and is suitable for high reliability communication demand scenarios.
Adopting a direct antenna installation design, the structure is compact.
ending:
Overall, Agilis ALB12822C8-VO performs well in terms of RF output performance, environmental adaptability, and remote monitoring function, making it a reliable up conversion power amplifier component in satellite communication systems.
Agilis ALB12822C8-VO 控制器模块 产品展示
