cPCIS-6230R电源模块 PDF资料
1.产 品 资 料 介 绍：
cPCIS-6230R 电源模块产品特点
cPCIS-6230R 是凌华科技（ADLINK）生产的一款2U上架式机箱，内置300W电源模块，主要为6U CompactPCI系统提供供电支持。
该型号主要产品特点：
标准19英寸2U机箱设计，适配工业机柜。
内置300W 1U ATX电源。
支持100至240V宽幅交流输入。
输出包括+5V、+3.3V、+12V、-12V。
具备过载、过压、短路、过热保护功能。
兼容PICMG 2.1热插拔规范。
提供3槽32位或64位cPCI背板。
可选H.110 CT总线，适用于电话应用。
内置光驱，预留硬盘安装位。
配备四个散热风扇，散热效果良好。
LED指示灯实时显示各路电压状态。
防误触电源开关和复位按钮。
工作温度0°C至+55°C。
符合多项安全认证标准。
适用于通信及工业控制领域。
总结：该机箱集成电源与背板于一体，结构紧凑、保护功能完善，为6U cPCI系统提供了稳定可靠的供电平台。
cPCIS-6230R电源模块 英文介绍
CPICS-6230R power module product features
CPICS-6230R is a 2U rack mounted chassis produced by ADLINK, with a built-in 300W power module, mainly providing power support for 6U CompactPCI systems.
The main product features of this model are:
Standard 19 inch 2U chassis design, compatible with industrial cabinets.
Built in 300W 1U ATX power supply.
Supports wide AC input from 100 to 240V.
The output includes+5V,+3.3V,+12V, and -12V.
Equipped with overload, overvoltage, short circuit, and overheating protection functions.
Compatible with PICMG 2.1 hot plug specification.
Provide 3-slot 32-bit or 64 bit cPCI backplanes.
Optional H.110 CT bus, suitable for telephone applications.
Built in optical drive, reserved hard drive installation space.
Equipped with four cooling fans, the cooling effect is good.
The LED indicator light displays the real-time voltage status of each channel.
Prevent accidental contact with the power switch and reset button.
The working temperature ranges from 0 ° C to+55 ° C.
Meets multiple safety certification standards.
Suitable for communication and industrial control fields.
Summary: This chassis integrates power supply and backplane, with a compact structure and complete protection functions, providing a stable and reliable power supply platform for the 6U cPCI system.
