REX010 HESG324426R1地面故障保护装置 PDF资料

1.产 品 资 料 介 绍：

REX010 HESG324426R1 地面故障保护装置

概述：
REX010 HESG324426R1 是一款用于电气系统的地面故障（接地故障）保护装置，主要用于检测和保护电力或控制系统中出现的接地泄漏或接地短路情况，从而预防设备损坏、人身安全事故及系统停机风险。

核心功能

1. 实时检测系统中的接地电流异常
2. 在出现地面（接地）故障时发出报警或切断保护输出
3. 提供多级故障判断和响应逻辑
4. 支持继电器输出用于联动切断电源或启动故障处理流程

技术特点

5. 适用于三相及单相电力系统的接地监测
6. 使用高灵敏度传感元件检测漏电流变化
7. 具有抗干扰能力，适合复杂现场环境
8. 内置故障状态指示及诊断信息

典型应用

9. 工业低压配电系统
10. 电动机及驱动系统保护
11. 建筑电气安全监测
12. 不接地或阻抗接地系统保护
13. 电气设备的预防性安全措施

使用要点

14. 安装在配电柜或接地监测点位置
15. 配合剩余电流互感器（RCT）实现接地电流感应
16. 定期检测装置状态，确保灵敏度正常
17. 调整报警阈值以适应系统特点

结尾：
REX010 HESG324426R1 地面故障保护装置通过持续监测接地电流及漏电情况，在故障发生初期及时响应，提升系统的安全性与可靠性，是电气系统中重要的保护组件。

REX010 HESG324426R1地面故障保护装置  英文介绍

REX010 HESG324426R1 Ground Fault Protection Device

Overview:

REX010 HESG324426R1 is a ground fault (ground fault) protection device for electrical systems, mainly used to detect and protect against ground leaks or short circuits in power or control systems, thereby preventing equipment damage, personal safety accidents, and system shutdown risks.

core functionality

Real time detection of abnormal grounding current in the system

Give an alarm or cut off the protection output when a ground (grounding) fault occurs

Provide multi-level fault diagnosis and response logic

Support relay output for linkage to cut off power or initiate fault handling process

Technical Features

Grounding monitoring applicable to three-phase and single-phase power systems

Using high-sensitivity sensing elements to detect changes in leakage current

Capable of anti-interference and suitable for complex on-site environments

Built in fault status indication and diagnostic information

Typical Applications

Industrial low-voltage distribution system

Motor and drive system protection

Building electrical safety monitoring

Non grounded or impedance grounded system protection

Preventive safety measures for electrical equipment

Key points for use

Installed at the location of the distribution cabinet or grounding monitoring point

Cooperate with residual current transformer (RCT) to achieve grounding current induction

Regularly check the status of the device to ensure normal sensitivity

Adjust alarm threshold to adapt to system characteristics

ending:

The REX010 HESG324426R1 ground fault protection device continuously monitors the grounding current and leakage situation, responds promptly in the early stages of a fault, and improves the safety and reliability of the system. It is an important protective component in electrical systems.

REX010 HESG324426R1地面故障保护装置 产品展示
