1769-ADN适配器模块 PDF资料
1.产 品 资 料 介 绍：
1769-ADN 适配器模块
产品说明
1769-ADN是一款基于DeviceNet总线的远程I/O适配器，用于将1769系列模块接入分布式控制系统，实现PLC与现场设备之间的数据交换。
主要特点
- 支持DeviceNet协议，适用于工业现场总线通信
- 可扩展最多30个1769本地I/O模块
- 支持轮询、位触发、变化触发等通信方式
- 具备节点地址配置与波特率选择功能
- 提供LED诊断指示（网络、电源、模块状态）
- 支持从站模式，适用于远程I/O架构
- 抗干扰能力强，适合复杂工业环境
技术要点
- 通信速率：125 / 250 / 500 kbps
- 电源：由1769电源模块供电
- 安装方式：DIN导轨或面板安装
- 背板总线：与1769模块本地高速通信
- 工作温度：0～60℃
应用场景
- 生产线分布式I/O系统
- 包装与物流自动化设备
- 汽车制造及装配线
- 工业设备远程控制与监测
核心优势
- 实现远程I/O集中管理，减少布线
- 系统扩展灵活，兼容性强
- 通信稳定，适合实时控制应用
1769-ADN适配器模块 英文介绍
1769-ADN adapter module
Product Description
1769-ADN is a remote I/O adapter based on DeviceNet bus, used to connect 1769 series modules to distributed control systems and achieve data exchange between PLCs and field devices.
Main Features
Supports DeviceNet protocol, suitable for industrial fieldbus communication
Expandable up to 30 1769 local I/O modules
Support communication methods such as polling, bit triggering, and change triggering
Capable of configuring node addresses and selecting baud rates
Provide LED diagnostic indicators (network, power, module status)
Supports slave mode, suitable for remote I/O architecture
Strong anti-interference ability, suitable for complex industrial environments
Technical Points
Communication speed: 125/250/500 kbps
Power supply: Powered by 1769 power module
Installation method: DIN rail or panel installation
Backplane bus: Local high-speed communication with 1769 module
Working temperature: 0-60 ℃
Application scenarios
Distributed I/O System for Production Line
Packaging and logistics automation equipment
Automobile manufacturing and assembly line
Remote control and monitoring of industrial equipment
Core strengths
Realize centralized management of remote I/O and reduce wiring
Flexible system expansion and strong compatibility
Stable communication, suitable for real-time control applications
