AFP87432输入/输出端子板 PDF资料
1.产 品 资 料 介 绍：
AFP87432 输入/输出端子板是一块用于PLC系统的扩展模块，主要功能是让PLC与现场设备（如开关、传感器、继电器、指示灯等）进行信号交互。
主要功能
输入信号接收
接入现场数字信号，例如按钮、限位开关或传感器的开关量。
常见输入电压为DC 24V。
输出信号控制
输出控制信号到外部设备，通过继电器开关控制灯、继电器线圈等负载。
每路输出一般可承载约2A负载。
端子连接
采用螺丝式端子，便于现场接线和维护。
在PLC系统中的作用
扩展PLC主控制器的输入输出点数。
PLC通过总线与端子板通讯，实现读取输入信号和控制输出信号。
使PLC能够更方便地与现场设备连接，构建完整的控制系统。
典型规格
输入点数：16点
输出点数：8路继电器输出
输入电压：DC 24V
输出负载能力：约2A
连接方式：螺丝端子
AFP87432输入/输出端子板 英文介绍
AFP87432 input/output terminal board is an expansion module for PLC systems, mainly used for signal interaction between PLC and field devices such as switches, sensors, relays, indicator lights, etc.
Main functions
Input signal reception
Connect on-site digital signals, such as the on/off values of buttons, limit switches, or sensors.
The common input voltage is DC 24V.
Output signal control
Output control signals to external devices and control loads such as lights and relay coils through relay switches.
Each output can generally carry a load of about 2A.
terminal connection
Using screw type terminals for easy on-site wiring and maintenance.
Function in PLC system
Expand the input and output points of the PLC main controller.
PLC communicates with the terminal board through the bus to read input signals and control output signals.
Enable PLC to easily connect with on-site equipment and build a complete control system.
Typical specifications
Input points: 16 points
Output points: 8 relay outputs
Input voltage: DC 24V
Output load capacity: approximately 2A
Connection method: screw terminal
AFP87432输入/输出端子板 产品展示
