Motorola MVME-717传送器 I/O 模块 PDF资料

1.产 品 资 料 介 绍：

Motorola MVME-717 传送器 I/O 模块

产品概述

Motorola MVME-717 是一款基于 VMEbus 架构的传送器 I/O 模块，用于 MVME717 系列单板计算机系统。该模块提供 数字量和模拟量信号采集与输出接口，用于连接传感器、执行器及外围设备，实现工业自动化、测试测量及嵌入式控制系统的数据采集和控制功能。MVME-717 可与 MVME717 系列 CPU 模块及其他 VME 扩展模块协同工作，保证系统在复杂环境下的可靠性和实时性。

技术参数

• 总线接口：VMEbus 标准，支持 16/32 位数据传输

• I/O 类型：

• 数字输入/输出通道

• 模拟输入/输出通道

• 支持继电器控制或传感器信号接口

• 控制功能：

• CPU 可编程控制

• 支持中断触发和状态反馈

• 数据缓冲与同步传输

• 兼容性：与 MVME717 系列 CPU 模块及 VME 扩展模块兼容

• 工作环境：工业级设计，抗干扰能力强，适合长期连续运行

应用场景

1. 工业自动化控制

• 对传感器、执行器及设备进行数据采集和控制，实现生产线自动化。

2. 机床与运动控制系统

• 提供多通道输入/输出接口，实现多轴运动控制和状态监控。

3. 测试与测量系统

• 采集实验或生产数据，控制实验设备或工业仪器。

4. 通信与嵌入式系统

• 管理外部设备的数据传输和接口切换，实现嵌入式通信。

5. 能源与电力系统

• 对监测设备、传感器及执行装置进行集中采集和控制。

Motorola  MVME-717传送器 I/O 模块 英文资料：

Motorola MVME-717 transmitter I/O module

Product Overview

Motorola MVME-717 is a transmitter I/O module based on the VMEbus architecture, used for the MVME717 series single board computer systems. This module provides interfaces for digital and analog signal acquisition and output, which are used to connect sensors, actuators, and peripheral devices to achieve data acquisition and control functions for industrial automation, testing and measurement, and embedded control systems. MVME-717 can work in conjunction with MVME717 series CPU modules and other VME expansion modules to ensure the reliability and real-time performance of the system in complex environments.

Technical Specifications

Bus interface: VMEbus standard, supports 16/32-bit data transmission

I/O type:

Digital input/output channel

Analog input/output channel

Support relay control or sensor signal interface

Control function:

CPU programmable control

Support interrupt triggering and status feedback

Data buffering and synchronous transmission

Compatibility: Compatible with MVME717 series CPU modules and VME expansion modules

Work environment: Industrial grade design, strong anti-interference ability, suitable for long-term continuous operation

Application scenarios

industrial automation control

Collect and control data from sensors, actuators, and equipment to achieve production line automation.

Machine Tool and Motion Control System

Provide multi-channel input/output interfaces to achieve multi axis motion control and status monitoring.

Testing and Measurement System

Collect experimental or production data, control experimental equipment or industrial instruments.

Communication and Embedded Systems

Manage data transmission and interface switching of external devices to achieve embedded communication.

Energy and Power Systems

Centralize the collection and control of monitoring equipment, sensors, and execution devices.

Motorola MVME-717传送器 I/O 模块 产品展示
